4 Flutes JJ Rib Corner Radius End Mills for Hardened Steels
4
mm JJ series
Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia DR of cut Length Length Dia
4JJCR 015 0005 080 DR L1 L2 L d 4JJCR 020 005 120
4JJCR 015 0005 100 4JJCR 020 005 160 L1 L2 L d
4JJCR 015 0005 120 1.5XR0.05 1.5 8 45 4 4JJCR 020 005 200
4JJCR 015 0005 160 1.5XR0.05 1.5 10 50 4 4JJCR 020 005 250 2 X R0.5 2 12 50 4
4JJCR 015 001 060 1.5XR0.05 1.5 12 50 4 4JJCR 025 001 100
4JJCR 015 001 080 1.5XR0.05 1.5 16 50 4 4JJCR 025 001 160 2 X R0.5 2 16 50 4
4JJCR 015 001 100 1.5 X R0.1 1.5 6 45 4 4JJCR 025 001 200
4JJCR 015 001 120 1.5 X R0.1 1.5 8 45 4 4JJCR 025 001 250 2 X R0.5 2 20 50 4
4JJCR 015 001 160 1.5 X R0.1 1.5 10 50 4 4JJCR 025 002 100
4JJCR 015 002 060 1.5 X R0.1 1.5 12 50 4 4JJCR 025 002 160 2 X R0.5 2 25 60 4
4JJCR 015 002 080 1.5 X R0.1 1.5 16 50 4 4JJCR 025 002 200
4JJCR 015 002 100 1.5 X R0.2 1.5 6 45 4 4JJCR 025 002 250 2.5 X R0.1 2.5 10 50 4
4JJCR 015 002 120 1.5 X R0.2 1.5 8 45 4 4JJCR 025 003 100
4JJCR 015 002 160 1.5 X R0.2 1.5 10 50 4 4JJCR 025 003 160 2.5 X R0.1 2.5 16 50 4
4JJCR 015 003 060 1.5 X R0.2 1.5 12 50 4 4JJCR 025 003 200
4JJCR 015 003 080 1.5 X R0.2 1.5 16 50 4 4JJCR 025 003 250 2.5 X R0.1 2.5 20 50 4
4JJCR 015 003 100 1.5 X R0.3 1.5 6 45 4 4JJCR 025 005 100
4JJCR 015 003 120 1.5 X R0.3 1.5 8 45 4 4JJCR 025 005 160 2.5 X R0.1 2.5 25 60 4
4JJCR 015 003 160 1.5 X R0.3 1.5 10 50 4 4JJCR 025 005 200
4JJCR 015 005 060 1.5 X R0.3 1.5 12 50 4 4JJCR 025 005 250 2.5 X R0.2 2.5 10 50 4
4JJCR 015 005 080 1.5 X R0.3 1.5 16 50 4 4JJCR 030 001 100
4JJCR 015 005 100 1.5 X R0.5 1.5 6 45 4 4JJCR 030 001 120 2.5 X R0.2 2.5 16 50 4
4JJCR 015 005 120 1.5 X R0.5 1.5 8 45 4 4JJCR 030 001 160
4JJCR 015 005 160 1.5 X R0.5 1.5 10 50 4 4JJCR 030 001 200 2.5 X R0.2 2.5 20 50 4
4JJCR 020 0002 060 1.5 X R0.5 1.5 12 50 4 4JJCR 030 001 250
4JJCR 020 0002 080 1.5 X R0.5 1.5 16 50 4 4JJCR 030 001 300 2.5 X R0.2 2.5 25 60 4
4JJCR 020 0002 100 2 X R0.02 2 6 45 4 4JJCR 030 001 350
4JJCR 020 0002 120 2 X R0.02 2 8 45 4 4JJCR 030 002 100 2.5 X R0.3 2.5 10 50 4
4JJCR 020 0002 160 2 X R0.02 2 10 50 4 4JJCR 030 002 120
4JJCR 020 0002 200 2 X R0.02 2 12 50 4 4JJCR 030 002 160 2.5 X R0.3 2.5 16 50 4
4JJCR 020 0002 250 2 X R0.02 2 16 50 4 4JJCR 030 002 200
4JJCR 020 0005 060 2 X R0.02 2 20 50 4 4JJCR 030 002 250 2.5 X R0.3 2.5 20 50 4
4JJCR 020 0005 080 2 X R0.02 2 25 60 4 4JJCR 030 002 300
4JJCR 020 0005 100 2 X R0.05 2 6 45 4 4JJCR 030 002 350 2.5 X R0.3 2.5 25 60 4
4JJCR 020 0005 120 2 X R0.05 2 8 45 4 New 4JJCR 030 002 400
4JJCR 020 0005 160 2 X R0.05 2 10 50 4 4JJCR 030 003 100 2.5 X R0.5 2.5 10 50 4
4JJCR 020 0005 200 2 X R0.05 2 12 50 4 4JJCR 030 003 120
4JJCR 020 0005 250 2 X R0.05 2 16 50 4 4JJCR 030 003 160 2.5 X R0.5 2.5 16 50 4
4JJCR 020 001 060 2 X R0.05 2 20 50 4 4JJCR 030 003 200
4JJCR 020 001 080 2 X R0.05 2 25 60 4 4JJCR 030 003 250 2.5 X R0.5 2.5 20 50 4
4JJCR 020 001 100 2 X R0.1 2 6 45 4 4JJCR 030 003 300
4JJCR 020 001 120 2 X R0.1 2 8 45 4 4JJCR 030 003 350 2.5 X R0.5 2.5 25 60 4
4JJCR 020 001 160 2 X R0.1 2 10 50 4 New 4JJCR 030 003 400
4JJCR 020 001 200 2 X R0.1 2 12 50 4 4JJCR 030 005 100 3 X R0.1 3 10 50 6
4JJCR 020 001 250 2 X R0.1 2 16 50 4 4JJCR 030 005 120
4JJCR 020 002 060 2 X R0.1 2 20 50 4 4JJCR 030 005 160 3 X R0.1 3 12 50 6
4JJCR 020 002 080 2 X R0.1 2 25 60 4 4JJCR 030 005 200
4JJCR 020 002 100 2 X R0.2 2 6 45 4 4JJCR 030 005 250 3 X R0.1 3 16 55 6
4JJCR 020 002 120 2 X R0.2 2 8 45 4 4JJCR 030 005 300
4JJCR 020 002 160 2 X R0.2 2 10 50 4 4JJCR 030 005 350 3 X R0.1 3 20 60 6
4JJCR 020 002 200 2 X R0.2 2 12 50 4 New 4JJCR 030 005 400
4JJCR 020 002 250 2 X R0.2 2 16 50 4 4JJCR 030 010 100 3 X R0.1 3 25 65 6
4JJCR 020 003 060 2 X R0.2 2 20 50 4 4JJCR 030 010 120
4JJCR 020 003 080 2 X R0.2 2 25 60 4 4JJCR 030 010 160 3 X R0.1 3 30 70 6
4JJCR 020 003 100 2 X R0.3 2 6 45 4 4JJCR 030 010 200
4JJCR 020 003 120 2 X R0.3 2 8 45 4 4JJCR 030 010 250 3 X R0.1 3 35 75 6
4JJCR 020 003 160 2 X R0.3 2 10 50 4 4JJCR 030 010 300
4JJCR 020 003 200 2 X R0.3 2 12 50 4 4JJCR 030 010 350 3 X R0.2 3 10 50 6
4JJCR 020 003 250 2 X R0.3 2 16 50 4 New 4JJCR 030 010 400
4JJCR 020 005 060 2 X R0.3 2 20 50 4 4JJCR 040 001 130 3 X R0.2 3 12 50 6
4JJCR 020 005 080 2 X R0.3 2 25 60 4 4JJCR 040 001 160
4JJCR 020 005 100 2 X R0.5 2 6 45 4 4JJCR 040 001 200 3 X R0.2 3 16 55 6
2 X R0.5 2 8 45 4
2 X R0.5 2 10 50 4 3 X R0.2 3 20 60 6
3 X R0.2 3 25 65 6
3 X R0.2 3 30 70 6
3 X R0.2 3 35 75 6
3 X R0.2 3 40 80 6
3 X R0.3 3 10 50 6
3 X R0.3 3 12 50 6
3 X R0.3 3 16 55 6
3 X R0.3 3 20 60 6
3 X R0.3 3 25 65 6
3 X R0.3 3 30 70 6
3 X R0.3 3 35 75 6
3 X R0.3 3 40 80 6
3 X R0.5 3 10 50 6
3 X R0.5 3 12 50 6
3 X R0.5 3 16 55 6
3 X R0.5 3 20 60 6
3 X R0.5 3 25 65 6
3 X R0.5 3 30 70 6
3 X R0.5 3 35 75 6
3 X R0.5 3 40 80 6
3 X R1 3 10 50 6
3 X R1 3 12 50 6
3 X R1 3 16 55 6
3 X R1 3 20 60 6
3 X R1 3 25 65 6
3 X R1 3 30 70 6
3 X R1 3 35 75 6
3 X R1 3 40 80 6
4 X R0.1 4 13 55 6
4 X R0.1 4 16 55 6
4 X R0.1 4 20 60 6
