WCMX / SPMX

▶ WCMX 치수 Dimension(mm) 부품 Parts

Code No. l d t r ød1 Screw Driver
TXL-6
WCMX030204 PA 3.8 5.56 2.38 0.4 2.5 TSB-22045 TXL-8
WCMX040204 PA 4.3 6.35 2.38 0.4 2.8 TSB-25055
WCMX050308 PA 5.4 7.94 3.18 0.8 3.4 TSB-30070 TXL-15
WCMX06T308 PA 6.5 9.525 3.97 0.8 4.4 TSB-35090
WCMX080408 PA 8.7 12.7 4.76 0.8 5.5 TSB-40110

Code No. 피삭재 Workpiece 적용 드릴 For Drill
PMKN S
WCMX030204 PA ◎◯◯△△ HSD(MCD) VLT(TMD) VMD TPD
WCMX040204 PA ◎◯◯△△
WCMX050308 PA ◎◯◯△△ ø16.0 ~ø20.0 ø25 ø45 ~ø55 -

WCMX06T308 PA ◎◯◯△△ ø20.5 ~ø25.0 ø26.0 ~ø30.0 ø55 ~ø60 -
WCMX080408 PA
◎◯◯△△ ø25.5 ~ø30.0 ø31.0 ~ø40.0 ø60 ~ø75 ø40~ø55
- ø60.0 ~ø75.0 ø100 ~ø105

ø31.0 ~ø41.0 ø41.0 ~ø50.0 ø75 ~ø100 ø60~ø110
ø59.0 ~ø80.0 ø75.0 ~ø80.0 ø105 ~ø140
-
ø42.0 ~ø58.0 ø51.0 ~ø59.0 ø140 ~ø180

ACCESSORIES ▶ SPMX 치수 Dimension(mm) 부품 Parts

Code No. d t r ød1 Screw Driver

SPMX050204 PA 5.00 2.38 0.4 2.25 TSB-20045 TXL-6
SPMX060204 PA 6.00 2.38 0.4 2.61 TSB-22052 TXL-8
SPMX07T308 PA 7.94 3.97 0.8 2.85 TSB-25065 TXL-15
SPMX090408 PA 9.80 4.30 0.8 4.05 TSB-35090 TXL-20
SPMX110408 PA 11.50 4.80 0.8 4.45 TSB-40100
SPMX140512 PA 14.30 5.20 1.2 5.75 TSB-50125

Code No. 피삭재 Workpiece 적용 드릴 For Drill

SPMX050204 PA PMKN S STD-V FXD
SPMX060204 PA ◎◯◯△ △
SPMX07T308 PA ◎◯◯△ △ ø13.0 ~ø15.0 ø18.0 ~ø19.5
◎◯◯△ △ ø15.5 ~ø21.5 ø20.0 ~ø25.0
SPMX090408 PA ø22.0 ~ø27.5 ø25.5 ~ø30.0
◎◯◯△ △ ø28.0 ~ø33.0
ø50.0 ~ø60.0 -
SPMX110408 PA ◎ ◯ ◯ △ △ ø34.0 ~ø41.0 -
ø60.0 ~ø75.0 -
SPMX140512 PA ◎ ◯ ◯ △ △ ø42.0 ~ø50.0 -
ø75.0 ~ø80.0 -
-
