● DIN2080 / NT EMS Standard Type Holder
▶ NT-ETA

Group Code No. 치수 Dimension(mm) 부품 Component
EMS40 NT40-ETA-22040
TOOL HOLDER EMS50 NT40-ETA-28045 EMS dL M B
EMS63 NT40-ETA-36065 40 22 40 5/8″-11UNC MTB-10145
EMS50 NT50-ETA-28055 50 28 45 1″-8UNC MTB-12175
EMS63 NT50-ETA-36060 63 36 65 MTB-16225
EMS80 NT50-ETA-45060 50 28 55 M16 MTB-12175
EMS40 NT40-ETA-22040M 63 36 60 M24 MTB-16225
EMS50 NT40-ETA-28045M 80 45 60 MTB-16260
EMS63 NT40-ETA-36065M 40 22 40 MTB-10145
EMS50 NT50-ETA-28055M 50 28 45 MTB-12175
EMS63 NT50-ETA-36060M 63 36 65 MTB-16225
EMS80 NT50-ETA-45060M 50 28 55 MTB-12175
63 36 60 MTB-16225
80 45 60 MTB-16260

● DIN228B / MT EMS Standard Type Holder
▶ MT-ETA

Group Code No. EMS 치수 Dimension(mm) L 부품 Component
d 45
60 B
EMS40 MT4-ETA-22045 40 22 65 MTB-10145
EMS50 MT4-ETA-28060 50 28 45 MTB-12175
EMS63 MT4-ETA-36065 63 36 60 MTB-16225
EMS40 MT5-ETA-22045 40 22 65 MTB-10145
EMS50 MT5-ETA-28060 50 28 75 MTB-12175
EMS63 MT5-ETA-36065 63 36 65 MTB-16225
EMS80 MT5-ETA-45075 80 45 75 MTB-16260
EMS63 MT6-ETA-36065 63 36 MTB-16225
EMS80 MT6-ETA-45075 80 45 MTB-16260

※ 코터홈이 있는 경우 별도 지정해 주시기 바랍니다.
※ If a COTTER HOME is present, please make a separate assignment.
