MIRAEPO NC TOTAL TOOLING SYSTEM
▣ Corner Rounding Cutter (코너 라운딩 커터)
Fig1 150 ∅D
∅D
∅d1
R
Fig3
Fig2 ∅d1
∅d1 ∅D
R 150 R 150
규격 Fig R D d1 적용insert 가 격
~4.0 20
ST20-CRC045-150-09 2 ~6.0 20 SPRR09 104,500
~8.0 32
ST20-CRC065-150-12 1 ~4.0 21 SPRR12 89,300
ST20-CRC085-150-12 ~6.0 42 89,300
~8.0
ST32-CRC040-150-12 ~4.0 115,500
~6.0
ST32-CRC065-150-12 2 ~8.0 28 SPRR12 115,500
~10.0
ST32-CRC085-150-12 ~10.0 115,500
~12.0
ST32-CRC040-150-15 ~14.0 115,500
~15.0
ST32-CRC065-150-15 ~16.0 115,500
~16.0 38 SPRR15
ST32-CRC085-150-15 ~18.0
~20.0 115,500
~22.0
ST32-CRC105-150-15 ~25.0 159,500
~27.0
ST32-CRC105-150-19 159,500
ST32-CRC125-150-19 159,500
ST32-CRC145-150-19
3 48 SPRR19 159,500
ST32-CRC155-150-19 159,500
ST32-CRC165-150-19 159,500
ST32-CRC165-150-25 159,500
ST32-CRC185-150-25 56 SPRR25 159,500
ST32-CRC200-150-25 159,500
ST42-CRC220-150-32 275,000
ST42-CRC250-150-32 3 68 SPRR32 316,200
ST42-CRC270-150-32 316,200
