Hydraulic
Chuck

ER COLLET - GER (고정밀형) GER Shrink Fit
Holder
(원산지 : 독일)

Milling
Chuck

SK Slim
Chuck

* T.I.R : ≤0.005mm at 3D

TYPE GER 8 TYPE GER 16 TYPE GER 25 TYPE GER 32 Unit : mm ER Collet
TYPE GER 40 Chuck

CLAMPING CODE No. CLAMPING CODE No. CLAMPING CODE No. CLAMPING CODE No. CLAMPING CODE No. N&COHDtroilhlledreCrThsouoclk
RANGE RANGE RANGE RANGE RANGE

1.0 ~ 0.5 108010 1.0 ~ 0.5 116010 2.0 ~ 1.0 125020 3.0 ~ 2.0 132030 4.0 ~ 3.0 140040 Morse TaperArbor
1.5 ~ 1.0 108015 2.0 ~ 1.0 116020 3.0 ~ 2.0 125030 4.0 ~ 3.0 132040 5.0 ~ 4.0 140050
2.0 ~ 1.5 108020 3.0 ~ 2.0 116030 4.0 ~ 3.0 125040 5.0 ~ 4.0 132050 6.0 ~ 5.0 140060 Synchro Tapping Chuck
2.5 ~ 2.0 108025 4.0 ~ 3.0 116040 5.0 ~ 4.0 125050 6.0 ~ 5.0 132060 7.0 ~ 6.0 140070
3.0 ~ 2.5 108030 5.0 ~ 4.0 116050 6.0 ~ 5.0 125060 7.0 ~ 6.0 132070 8.0 ~ 7.0 140080
3.5 ~ 3.0 108035 6.0 ~ 5.0 116060 7.0 ~ 6.0 125070 8.0 ~ 7.0 132080 9.0 ~ 8.0 140090
4.0 ~ 3.5 108040 7.0 ~ 6.0 116070 8.0 ~ 7.0 125080 9.0 ~ 8.0 132090 10.0 ~ 9.0 140100
4.5 ~ 4.0 108045 8.0 ~ 7.0 116080 9.0 ~ 8.0 125090 10.0 ~ 9.0 132100 11.0 ~ 10.0 140110
5.0 ~ 4.5 108050 9.0 ~ 8.0 116090 10.0 ~ 9.0 125100 11.0 ~ 10.0 132110 12.0 ~ 11.0 140120
10.0 ~ 9.0 116100 11.0 ~ 10.0 125110 12.0 ~ 11.0 132120 13.0 ~ 12.0 140130
TYPE GER 11 1.5 ~ 1.0 116015 12.0 ~ 11.0 125120 13.0 ~ 12.0 132130 14.0 ~ 13.0 140140
2.5 ~ 2.0 116025 13.0 ~ 12.0 125130 14.0 ~ 13.0 132140 15.0 ~ 14.0 140150
CLAMPING CODE No. 14.0 ~ 13.0 125140 15.0 ~ 14.0 132150 16.0 ~ 15.0 140160
RANGE 15.0 ~ 14.0 125150 16.0 ~ 15.0 132160 17.0 ~ 16.0 140170 Tapping ER
16.0 ~ 15.0 125160 17.0 ~ 16.0 132170 18.0 ~ 17.0 140180 Chuck
1.0 ~ 0.5 111010 TYPE GER 20 1.0 ~ 1.5 125010 18.0 ~ 17.0 132180 19.0 ~ 18.0 140190
1.5 ~ 1.0 111015 1.5 ~ 1.0 125015 19.0 ~ 18.0 132190 20.0 ~ 19.0 140200
2.0 ~ 1.5 111020 CLAMPING CODE No. 2.5 ~ 2.0 125025 20.0 ~ 19.0 132200 21.0 ~ 20.0 140210
2.5 ~ 2.0 111025 RANGE 2.0 ~ 1.0 132020 22.0 ~ 21.0 140220
3.0 ~ 2.5 111030 2.5 ~ 2.0 132025 23.0 ~ 22.0 140230
3.5 ~ 3.0 111035 2.0 ~ 1.0 120020 24.0 ~ 23.0 140240 Tapping
4.0 ~ 3.5 111040 3.0 ~ 2.0 120030 25.0 ~ 24.0 140250 Chuck
4.5 ~ 4.0 111045 4.0 ~ 3.0 120040 26.0 ~ 25.0 140260
5.0 ~ 4.5 111050 5.0 ~ 4.0 120050 3.0 ~ 2.0 140030 Side Lock Arbor
5.5 ~ 5.0 111055 6.0 ~ 5.0 120060 27.0 ~ 26.0 140270 & End Mill Holder
6.0 ~ 5.5 111060 7.0 ~ 6.0 120070 28.0 ~ 27.0 140280
6.5 ~ 6.0 111065 8.0 ~ 7.0 120080 29.0 ~ 28.0 140290
7.0 ~ 6.5 111070 9.0 ~ 8.0 120090 30.0 ~ 29.0 140300
10.0 ~ 9.0 120100
11.0 ~ 10.0 120110 Face Mill
12.0 ~ 11.0 120120 Arbor
13.0 ~ 12.0 120130
1.0 ~ 0.5 120010 Shell Mill
1.5 ~ 1.0 120015 Arbor
2.5 ~ 2.0 120025
