Page 109 - SSK

Hydraulic
Chuck

EXTENSION ER COLLET CHUCK ER Shrink Fit
Holder
H
Milling
Chuck

D1 D2

L1 L2 NUT SK Slim
Chuck

STRAIGHT-K (SLIM TYPE) Unit : mm ER Collet
Chuck
TAPER No. MODEL No. CLAMPING RANGE D D1 L1 L2 H NUT / COLLET 중량(Kg) 재고
12 0.10 N&COHDtroilhlledreCrThsouoclk
16 K12-ER8M-70 0.5 - 5.0 12 12 70 25 38 XSQ-R8M / ER8 0.22
20 K12-ER8M-100 0.5 - 5.0 12 12 100 25 38 XSQ-R8M / ER8 Morse TaperArbor
K12-ER8M-150 0.5 - 5.0 12 12 150 25 38 XSQ-R8M / ER8 0.32
25 K12-ER8M-200 0.5 - 5.0 12 12 200 25 38 XSQ-R8M / ER8 0.35 Synchro Tapping Chuck
K12-ER8M-250 0.5 - 5.0 12 12 250 25 38 XSQ-R8M / ER8 0.45
32 K12-ER8M-300 0.5 - 5.0 12 12 300 25 38 XSQ-R8M / ER8 0.52 Tapping ER
K16-ER11M-100 0.5 - 7.0 16 16 100 32 29.5 XSQ-R11M / ER11 0.55 Chuck
K16-ER11M-140 0.5 - 7.0 16 16 140 32 29.5 XSQ-R11M / ER11
K16-ER11M-200 0.5 - 7.0 16 16 200 32 29.5 XSQ-R11M / ER11 Tapping
K16-ER11M-250 0.5 - 7.0 16 16 250 32 29.5 XSQ-R11M / ER11 Chuck
K16-ER11M-300 0.5 - 7.0 16 16 300 32 29.5 XSQ-R11M / ER11
K16-ER16M-100 0.5 - 10.0 16 22 100 32 38 XSQ-R16M / ER16 Side Lock Arbor
K16-ER16M-140 0.5 - 10.0 16 22 140 32 38 XSQ-R16M / ER16 & End Mill Holder
K16-ER16M-200 0.5 - 10.0 16 22 200 32 38 XSQ-R16M / ER16
K16-ER16M-250 0.5 - 10.0 16 22 250 32 38 XSQ-R16M / ER16 Face Mill
K16-ER16M-300 0.5 - 10.0 16 22 300 32 38 XSQ-R16M / ER16 Arbor
K20-ER16M-100 0.5 - 10.0 20 22 100 41 - XSQ-R16M / ER16
K20-ER16M-140 0.5 - 10.0 20 22 140 41 - XSQ-R16M / ER16 Shell Mill
K20-ER16M-200 0.5 - 10.0 20 22 200 41 - XSQ-R16M / ER16 Arbor
K20-ER16M-250 0.5 - 10.0 20 22 250 41 - XSQ-R16M / ER16
K20-ER16M-300 0.5 - 10.0 20 22 300 41 - XSQ-R16M / ER16 Boring
K20-ER20M-100 0.5 - 13.0 20 28 100 41 41.5 XSQ-R20M / ER20 System
K20-ER20M-140 0.5 - 13.0 20 28 140 41 41.5 XSQ-R20M / ER20
K20-ER20M-200 0.5 - 13.0 20 28 200 41 41.5 XSQ-R20M / ER20
K20-ER20M-250 0.5 - 13.0 20 28 250 41 41.5 XSQ-R20M / ER20
K20-ER20M-300 0.5 - 13.0 20 28 300 41 41.5 XSQ-R20M / ER20
K25-ER16M-100 0.5 - 10.0 25 22 100 41 - XSQ-R16M / ER16
K25-ER16M-140 0.5 - 10.0 25 22 140 41 - XSQ-R16M / ER16
K25-ER16M-200 0.5 - 10.0 25 22 200 41 - XSQ-R16M / ER16
K25-ER16M-250 0.5 - 10.0 25 22 250 41 - XSQ-R16M / ER16
K25-ER16M-300 0.5 - 10.0 25 22 300 41 - XSQ-R16M / ER16
K25-ER20M-140 0.5 - 13.0 25 28 140 41 79 XSQ-R20M / ER20
K25-ER20M-200 0.5 - 13.0 25 28 200 41 79 XSQ-R20M / ER20
K25-ER20M-250 0.5 - 13.0 25 28 250 41 79 XSQ-R20M / ER20
K25-ER20M-300 0.5 - 13.0 25 28 300 41 79 XSQ-R20M / ER20
K25-ER25M-140 1.0 - 16.0 25 35 140 45 82 XSQ-R25M / ER25
K25-ER25M-200 1.0 - 16.0 25 35 200 45 82 XSQ-R25M / ER25
K25-ER25M-250 1.0 - 16.0 25 35 250 45 82 XSQ-R25M / ER25
K25-ER25M-300 1.0 - 16.0 25 35 300 45 82 XSQ-R25M / ER25
K32-ER20M-150 0.5 - 13.0 32 28 150 41 41.5 XSQ-R20M / ER20
K32-ER20M-200 0.5 - 13.0 32 28 200 41 41.5 XSQ-R20M / ER20
K32-ER20M-250 0.5 - 13.0 32 28 250 41 41.5 XSQ-R20M / ER20
K32-ER20M-300 0.5 - 13.0 32 28 300 41 41.5 XSQ-R20M / ER20
K32-ER25M-150 1.0 - 16.0 32 35 150 41 41.5 XSQ-R25M / ER25
K32-ER25M-200 1.0 - 16.0 32 35 200 41 41.5 XSQ-R25M / ER25
K32-ER25M-250 1.0 - 16.0 32 35 250 41 41.5 XSQ-R25M / ER25
K32-ER25M-300 1.0 - 16.0 32 35 300 41 41.5 XSQ-R25M / ER25
K32-ER25M-350 1.0 - 16.0 32 35 350 41 41.5 XSQ-R25M / ER25

TOOL CO., LTD. www.ssktool.co.kr 109 Accessory
