Hydraulic
Chuck

FACE MILL ARBOR FMA Shrink Fit
Holder
G
FIG.1

B Milling
D Chuck
C1

TAPER No. K M16 SK Slim
LH Chuck
FIG.2

B ER Collet
D Chuck
C1

TAPER No. K
LH

JIS B6339-BT JIS B6339 Taper G Value RPM Coolant N&COHDtroilhlledreCrThsouoclk
- BT Accuracy 6.3 15,000 System

AT3 AD

TAPER No. MODEL No. D L C1 H W K G FIG. 중량(Kg) Unit : mm Morse TaperArbor
30 BT30-FMA25.4-45 25.4 45 50 22 1.10 재고
40 BT30-FMA31.75-45 31.75 45 60 30 9.5 5 M12 1 1.20 ●
BT40-FMA25.4-45 25.4 45 50 22 1.50 ●
50 BT40-FMA25.4-90 25.4 90 50 22 12.7 7 M16 1 3.10 ●
BT40-FMA31.75-45 31.75 45 60 30 1.90
BT40-FMA31.75-75 31.75 75 60 30 9.5 5 M12 1 2.70 ●
BT40-FMA38.1-60 38.1 60 80 34 2.90
BT50-FMA25.4-45 25.4 45 50 22 9.5 5 M12 1 3.70 ● Synchro Tapping Chuck
BT50-FMA25.4-90 25.4 90 50 22 4.60 ●
BT50-FMA25.4-150 25.4 150 50 22 12.7 7 M16 1 5.50 ●
BT50-FMA31.75-45 31.75 45 60 30 4.50 ●
BT50-FMA31.75-75 31.75 75 60 30 12.7 7 M16 1 5.30 ●
BT50-FMA31.75-105 31.75 105 60 30 5.80 ●
BT50-FMA31.75-150 31.75 150 60 30 15.9 9 M20 1 6.30 ●
BT50-FMA38.1-45 38.1 45 80 34 4.30 ●
BT50-FMA38.1-75 38.1 75 80 34 9.5 5 M12 1 5.60 ● Tapping ER
BT50-FMA38.1-105 38.1 105 80 34 6.00 ● Chuck
BT50-FMA38.1-150 38.1 150 80 34 9.5 5 M12 1 6.50 ●
BT50-FMA50.8-45 50.8 45 100 36 4.90 ●
BT50-FMA50.8-75 50.8 75 100 36 9.5 5 M12 1 6.80 ●
BT50-FMA47.625-75 47.625 75 128.57 38 7.70 ●
12.7 7 M16 1 ●

12.7 7 M16 1

12.7 7 M16 1 Tapping
Chuck
12.7 7 M16 1

15.9 9 M20 1

15.9 9 M20 1

15.9 9 M20 1 Side Lock Arbor
& End Mill Holder
15.9 9 M20 1

19.05 10 M24 1

19.05 10 M24 1

25.4 12.5 - 2

▶ CAT(ANSI B5.50) Taper 및 Inch Type 제품 공급 가능 Face Mill
▶ 사용부품 176page 참고 Arbor
