FACE MILL ARBOR FMA Shrink Fit
Holder
G

G Milling
DB Chuck
CD
TAPER No. K SK Slim
H1 C1 Chuck
L
G Value
DIN 69893/ISO 12164-1-HSK FORM A DIN 69893 Taper 6.3 RPM Coolant ER Collet
- HSK Accuracy 15,000 System Chuck

- AD

Unit : mm

TAPER No. MODEL No. D C1 L H1 B K G 중량(Kg) 재고 N&COHDtroilhlledreCrThsouoclk
40A HSK40A-FMA25.4-50 25.4 50 50
50A HSK50A-FMA25.4-60 25.4 50 60 22 9.5 5 M12
63A HSK63A-FMA25.4-45 25.4 50 45
HSK63A-FMA31.75-50 31.75 60 50 22 9.5 5 M12
100A HSK100A-FMA25.4-45 25.4 50 45
HSK100A-FMA31.75-50 31.75 60 50 22 9.5 5 M12
HSK100A-FMA38.1-55 38.1 80 55
HSK100A-FMA50.8-60 50.8 100 60 30 12.7 7 M16

22 9.5 5 M12 Morse Taper

30 12.7 7 M16 Arbor

34 15.9 9 M20

36 19.05 10 M24

FACE MILL ARBOR Synchro Tapping Chuck

FMC Tapping ER
Chuck
K

W Tapping
Chuck

TAPER No. LH Side Lock Arbor
& End Mill Holder
DIN 69893/ISO 12164-1-HSK FORM A DIN 69893 Taper G Value RPM Coolant
- HSK Accuracy 6.3 15,000 System

- AD

Unit : mm Face Mill
Arbor
TAPER No. MODEL No. DC L H W K G 중량(Kg) 재고

HSK40A-FMC16-45 16 34 45 17 8 4 M8 0.40

40A HSK40A-FMC22-50 22 45 50 18 10 5 M10 0.50 ●

HSK40A-FMC27-60 27 68 60 20 12 7 M12 0.70

HSK50A-FMC16-40 16 34 40 17 8 4 M8 Shell Mill
Arbor
50A HSK50A-FMC22-50 22 45 50 18 10 5 M10

HSK50A-FMC27-60 27 70 60 20 12 6 M12

HSK63A-FMC22-45 22 45 45 18 10 5 M10 ●

63A HSK63A-FMC27-60 27 70 60 20 12 6 M12 ●

HSK63A-FMC32-60 32 85 60 22 14 7 M16 ● Boring
System
HSK100A-FMC22-50 22 45 50 18 10 5 M10

100A HSK100A-FMC27-60 27 70 60 20 12 6 M12

HSK100A-FMC32-60 32 85 60 22 14 7 M16
