MILLING CHUCK

▶ SINGLE MILLING CHUCK

MAS403 BT-C ㎜

CODE NO. d1 D2 D1 L1 L2 COLLET
20 19 59 75 65 K20
BT30 C20-75 20 19 59 90 65 K20
C20-90 20 19 59 80 65 K20
20 19 59 90 65 K20
C20-80 20 19 59 135 65 K20
25 25.5 62 90 70 K25
C20-90 25 25.5 62 135 70 K25
32 25 75 90 75 K32
C20-135 32 25.5 75 105 75 K32
32 25.5 75 135 75 K32
BT40 C25-90 20 19 59 105 65 K20
C25-135 20 19 59 150 65 K20
25 25.5 62 105 70 K25
C32-90 25 25.5 62 135 70 K25
32 25 75 110 75 K32
C32-105 32 25 75 135 75 K32
32 25 75 165 75 K32
C32-135 42 25 94 110 85 K42
42 25 94 135 85 K42
C20-105 42 25 94 165 85 K42

C20-150

C25-105

C25-135

BT50 C32-110
C32-135

C32-165

C42-110

C42-135

C42-165

Taper : AT3 | T.I.R ≥10 : /2.5xD | Coolant : AD

툴홀더 시스템
COOLANT

ㆍ내 부 급유 (Spindle Through)사용이 가능하며 사용시 ONK Collet를 적용하십시요.
