TOOL HTOOOLLDHEOLRDER SYSTEM7
DRILL TAPPER

▶ DRILL TAPPER CHUCK

DT-MT ㎜
드릴 능력
CODE NO. MT.NO 탭 능력 [TAPPING RANGE] [DRILLING BORE]
DT24
DT33 3 METRIC INCH PIPE Ø32
DT52 4
3 4 M4 - M24 U 3/16 - U 7/8 P 1/8 - P 1/2 Ø50
4 5
4 5 M8 - M34,M35 U 5/16 - U 11/4 P 1/8 - P1 Ø75
5 6
5 M20 - M60 U 7/8 - U2 P 1/2 - P1 3/4
6

NOTE
ㆍCotter Home 선정을 위한 기계 모델 및 회사명을 알려주십시요.

▶ DRILL TAPPER COLLET

툴홀더 시스템 T-M, T-U, T-P METRIC 표준규격 [STANDARD SIZE] ㎜
INCH 본체
CODE NO. PIPE M4, 5, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 27 [Application Drill Holder]
T24 METRIC U3/16, 1/4, 5/16, 3/8, 7/16, 1/2, 9/16, 5/8, 3/4, 7/8, 1 DT24
INCH P 1/8, 1/4, 3/8, 1/2
T33 PIPE M8, 10, 12, 14, 16, 18, 20, 22, 24, 27, 30, 33, 34 DT33
METRIC U 5/16, 3/8, 7/16, 1/2, 9/16, 5/8, 3/4, 7/8, 1, 1/8, 1/4
T52 INCH P1/8, 1/4, 3/8, 1/2, 3/4, 1 DT52
PIPE M20, 22, 24, 27, 30, 33, 36, 39, 42, 45, 48, 52, 60
U 7/8, 1, 1 1/8, 1 1/4, 1 3/8, 1 1/2, 1 3/4, 1 7/8, 2
P 1/2, 3/4, 1, 1 1/4, 1 1/2, 1 3/4
