[ ZS1(2)04, ZS204 series ] ► 측면 절삭 가공

피삭재 열처리강 > Technical Data

경도 HRc40 ~ HRc50 HRc50 ~ HRc55 HRc55 ~ HRc60 HRc60 ~ HRc65 HRc65 ~ HRc70 추천절삭조건표
외경(mm)
RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED
4
6 17,200 1,690 11,440 1,140 9,360 700 7,280 430 6,170 310
8
10 13,450 1,820 8,970 1,230 6,890 720 5,460 450 4,810 330
12
9,100 1,750 6,760 1,170 5,200 670 4,160 420 3,640 310
RPM = rev. / min.
FEED = mm / min. 8,000 1,630 5,330 1,090 4,160 620 3,320 400 2,860 280

6,830 1,630 4,550 1,010 3,450 580 2,730 370 2,420 260

1.0D

0.03D

[ ZSPM4...-.. series ]

피삭재 열처리강

경도 ~HRc40 HRc40 ~ HRc50 HRc50 ~ HRc55 HRc55 ~ HRc60 HRc60 ~ HRc65
D X R(mm)
3 X R0.5 RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED
4 X R0.5
6 X R0.5 9,550 6,500 6,900 4,150 4,550 2,750 2,850 1,150 1,900 610
6 X R1.0
8 X R1.0 7,950 7,000 5,750 4,600 4,000 3,200 2,550 1,350 1,750 700
8 X R2.0
10 X R1.0 5,800 7,650 4,100 4,900 2,900 3,500 1,850 1,850 1,350 795
10 X R2.0
12 X R2.0 5,800 7,650 4,100 4,900 2,900 3,500 1,850 1,850 1,350 795
12 X R3.0
4,350 7,650 3,050 4,900 2,200 3,500 1,400 1,850 995 795
RPM = rev. / min.
FEED = mm / min. 4,350 7,650 3,050 4,900 2,200 3,500 1,400 1,850 995 795

3,500 7,650 2,450 4,900 1,750 3,500 1,100 1,850 795 795

3,500 7,650 2,450 4,900 1,750 3,500 1,100 1,850 795 795

2,900 7,650 2,050 4,900 1,450 3,500 925 1,850 665 795

2,900 7,650 2,050 4,900 1,450 3,500 925 1,850 665 795

0.2R 0.1R

0.5D 0.5D 0.5D 0.5D
