[ ZSLNR series ]

피삭재 탄소강, 합금강 프리하든강 열처리강 열처리강 > Technical Data
(180~250HB) (HRc35~45) (HRc45~55) (HRc55~65)
표준절삭깊이비율 추천절삭조건표
절삭깊이 X 100% 절삭깊이 X 100% 절삭깊이 X 100% 절삭깊이 X 100%
Mill Dia R 목부길이 절삭깊이 n Vf n Vf n Vf n Vf
(mm) (mm) (mm) (mm) (min-1) (mm/min) (min-1) (mm/min) (min-1) (mm/min) (min-1) (mm/min)

4 0.032 48,000 1,102 28,000 518 20,000 320 20,000 288
0.1 6 0.019
38,700 800 25,000 461 18,000 288 18,000 256
8 0.015
0.8 12 0.012 29,025 600 20,000 369 16,200 259 16,200 230

0.2 4 0.056 29,025 570 20,000 350 16,200 246 16,200 219
6 0.032
4 0.038 48,000 1,102 28,000 518 20,000 320 20,000 288
6 0.024
8 0.024 38,700 800 25,000 461 18,000 288 18,000 256

0.1 10 0.015 32,400 1,359 27,540 1,039 24,300 815 22,680 666
12 0.015
16 0.009 26,244 990 22,307 842 19,683 660 18,371 539
20 0.006
4 0.070 23,328 880 19,829 748 17,496 587 16,330 479
6 0.040
20,412 770 17,350 655 15,309 514 14,288 419
1 8 0.040
0.2 10 0.025 18,144 609 15,422 453 13,608 399 12,701 320
12 0.025
16 0.015 18,144 533 15,422 420 13,608 342 12,701 266
20 0.010
6 0.040 13,608 399 11,567 315 10,206 257 9,526 200
0.3 10 0.025
16 0.015 32,400 1,359 27,540 1,039 24,300 815 22,680 666
20 0.010 26,244 990 22,307 842 19,683 660 18,371 539
4 0.042
8 0.036 23,328 880 19,829 748 17,496 587 16,330 479
0.1 12 0.036
15 0.023 20,412 770 17,350 655 15,309 514 14,288 419
20 0.018
4 0.070 18,144 609 15,422 453 13,608 399 12,701 320

1.5 8 0.060 18,144 533 15,422 420 13,608 342 12,701 266
0.2 12 0.060
15 0.038 13,608 399 11,567 315 10,206 257 9,526 200
20 0.030
8 0.060 26,244 990 22,307 842 19,683 660 18,371 539
0.3 15 0.038
20 0.030 20,412 770 17,350 655 15,309 514 14,288 419

18,144 533 15,422 420 13,608 342 12,701 266
13,608 399 11,567 315 10,206 257 9,526 200
24,930 1,130 20,956 868 18,711 678 556
22,680 1,027 19,278 873 17,010 685 17,364 559
18,144 822 15,422 698 13,608 548 15,876 447
14,112 568 11,995 423 10,584 373 12,701 298
14,112 568 11,995 423 10,584 373 298
24,930 1,130 20,956 868 18,711 678 9,878 556
22,680 1,027 19,278 873 17,010 685 9,878 559
18,144 822 15,422 698 13,608 548 17,364 447
14,112 568 11,995 423 10,584 373 15,876 298
14,112 568 11,995 423 10,584 373 12,701 298
22,680 1,027 19,278 873 17,010 685 9,878 559
14,112 568 11,995 423 10,584 373 9,878 298
14,112 568 11,995 423 10,584 373 15,876 298
9,878
9,878
