[ ZSLNR series ]

추천절삭조건표 피삭재 탄소강, 합금강 프리하든강 열처리강 열처리강
(180~250HB) (HRc35~45) (HRc45~55) (HRc55~65)
> Technical Data
표준절삭깊이비율 절삭깊이 X 100% 절삭깊이 X 100% 절삭깊이 X 100% 절삭깊이 X 100%
n Vf n Vf n Vf n Vf
Mill Dia R 목부길이 절삭깊이 (min-1) (mm/min) (min-1) (mm/min) (min-1) (mm/min) (min-1) (mm/min)
(mm) (mm) (mm) (mm)

0.5 0.020 50,000 258 50,000 205 50,000 180 50,000 160

0.2 0.05 1 0.014 50,000 258 50,000 205 50,000 180 50,000 160

1.5 0.008 50,000 240 45,900 202 45,900 170 45,900 153

2 0.008 42,000 202 36,700 176 36,700 162 36,700 147

1 0.021 50,000 585 50,000 456 50,000 336 50,000 320

1.5 0.016 50,000 585 45,000 456 45,000 336 45,000 320

0.3 0.05 2 0.012 45,000 530 45,000 420 45,000 300 45,000 290

2.5 0.010 40,000 471 40,000 373 40,000 267 40,000 258

3 0.008 35,000 412 35,000 326 30,000 200 30,000 194

1 0.025 50,000 580 50,000 461 40,000 320 36,000 270

1.5 0.020 50,000 580 50,000 461 40,000 320 36,000 270

2 0.016 45,000 520 45,000 410 36,000 290 34,000 240

0.05 2.5 0.015 40,500 480 40,500 370 33,400 270 30,600 220
40,000 410 40,000 330 32,800 240 25,600 200
0.4 3 0.014 36,000 380 36,000 300 29,400 200 22,920 180
3.5 0.012 30,000 320 30,000 250 21,600 160 19,200 150

4 0.008

2 0.028 45,000 520 45,000 410 36,000 290 34,000 240

0.1 3 0.016 40,000 410 40,000 330 32,800 240 25,600 200
30,000 320 30,000 250 21,600 160 19,200 150
4 0.010 50,000 898 40,000 464 30,000 378 28,000 315
50,000 898 40,000 464 30,000 378 28,000 315
1 0.030 45,000 810 36,000 414 27,000 315 24,500 261
40,000 820 32,000 378 24,000 279 20,000 234
2 0.023 28,800 540 19,400 280 18,000 250 15,000 200
28,800 480 19,400 260 18,000 250 15,000 200
0.05 3 0.017 50,000 898 40,000 464 30,000 378 28,000 315
4 0.017 50,000 898 40,000 464 30,000 378 28,000 315
45,000 810 36,000 414 27,000 315 24,500 261
5 0.011 40,000 720 32,000 378 24,000 279 20,000 234
28,800 540 19,400 280 18,000 250 15,000 200
0.5 6 0.008 28,800 480 19,400 260 18,000 250 15,000 200
1 0.035 50,000 1,159 37,830 600 28,200 390 23,000 320
40,000 830 27,800 440 23,600 280 21,000 230
2 0.030 24,000 490 18,000 300 17,800 240 15,000 210
24,000 466 18,000 285 17,800 228 15,000 200
0.1 3 0.020 24,000 451 18,000 276 17,800 221 15,000 193
4 0.020

5 0.013

6 0.013

2 0.035

4 0.024

0.6 0.1 6 0.015

8 0.013

10 0.009
