Solid Carbide Grooving & Carbide End Mills
Chamfering End Mills
초경 1날
1 Flute 조각 & 각도

엔드밀

CAR 1FUltrafine 60° 90° 120°

Item no. Dα L d D Tolerance (허용공차) L

제품코드 규격 각도 전장 샹크 0~-0.03 d ±1

EM23CA-0260004 0.2 60° 40 4 h6
EM23CA-0290004 0.2 90° 40 4
EM23CA-0212004 0.2 120° 40 4
EM23CA-0260006 0.2 60° 40 6
EM23CA-0290006 0.2 90° 40 6
EM23CA-0212006 0.2 120° 40 6
EM23CA-0260008 0.2 60° 53 8
EM23CA-0290008 0.2 90° 53 8
EM23CA-0212008 0.2 120° 53 8
EM23CA-0260010 0.2 60° 53 10
EM23CA-0290010 0.2 90° 53 10
EM23CA-0212010 0.2 120° 53 10

2014/15 DYC TOOLS LIST 131
