Carbide Broach Carbide Cutters
Cutters
초경 브로치 컷터

Item no. D Flute Length Item no. D Flute Length

제품코드 규격 날장 제품코드 규격 날장

BR01CA-140 Ø14~Ø15 BR01CA-410 Ø41
BR01CA-160 Ø16~Ø17
BR01CA-175 BR01CA-420 Ø42
BR01CA-180 Ø17.5
BR01CA-200 Ø18~Ø19 BR01CA-430 Ø43
BR01CA-210
BR01CA-215 Ø20 BR01CA-440 Ø44
BR01CA-225 Ø21
BR01CA-235 Ø21.5~Ø22 BR01CA-450 Ø45
BR01CA-245 Ø22.5~Ø23
BR01CA-255 Ø23.5~Ø24 BR01CA-460 Ø46
BR01CA-265 Ø24.5~Ø25
BR01CA-280 Ø25.5~Ø26 BR01CA-470 Ø47
BR01CA-290 Ø26.5~Ø27
BR01CA-300 Ø28 BR01CA-480 Ø48
BR01CA-310 Ø29
BR01CA-320 Ø30 BR01CA-490 Ø49
BR01CA-330 Ø31
BR01CA-340 Ø32 BR01CA-500 Ø50 40mm 55mm
BR01CA-350 Ø33
BR01CA-360 Ø34 BR01CA-510 Ø51
BR01CA-370 Ø35
BR01CA-380 Ø36 BR01CA-520 Ø52
BR01CA-390 Ø37
BR01CA-400 Ø38 40mm 55mm BR01CA-530 Ø53
Ø39
Ø40 BR01CA-540 Ø54

BR01CA-550 Ø55

BR01CA-560 Ø56

BR01CA-570 Ø57

BR01CA-580 Ø58

BR01CA-590 Ø59

BR01CA-600 Ø60

D Tolerance (허용공차) l

0~-0.03 d1 ±1

Ø19.05
