ER COLLET DIN 6499-B (ER-GN TYPE)

ER COLLET CHUCK & MACHINE SPINDLE DIMENSIONS.

Drawings with tolerance specification Clamp Type A BC D E F
on request mm mm mm Cone mm mm

0.5 - 5 ER 8MS 5.2 8 M10 0.75 8 13.0 7.5
0.5 - 7 ER11MS 7.5 11 M13 0.75 8 17.0 10.0
0.5 - 10 ER16MS 10.5 16 M19 1 8 22.0 13.0
1.0 - 13 ER20MS 13.5 20 M24 1 8 26.5 13.5

0.5 - 7 UM/ER11 7.5 11 M14 0.75 8 17.0 10.0
22.0 13.0
0.5 - 10 UM/ER16 10.5 16 M22 1.5 8 26.5 13.5

1.0 - 13 UM/ER20 13.5 20 M25 1.5 8

0.5 - 10 UX/ER16 10.5 16 M22 1.5 8 22.6 13.0

1.0 - 13 UX/ER20 13.5 20 M25 1.5 8 26.5 13.5

1.0 - 16 UX/ER25 18.0 25 M32 1.5 8 29.0 14.0

2.0 - 20 UX/ER32 23.5 32 M40 1.5 8 34.0 16.0

3.0 - 26 UX/ER40 30.5 40 M50 1.5 8 38.0 17.0

12 - 34 UX/ER50 38.0 50 M64 2 8 48.0 24.0

0.5 - 10 KM/ER16 10.5 16 M22 1.5 8 22.0 13.0

1.0 - 13 KM/ER20 13.5 20 M25 1.5 8 26.6 13.5

1.0 - 16 KM/ER25 18.0 25 M32 1.5 8 29.0 14.0

2.0 - 20 KM/ER32 23.5 32 M40 1.5 8 34.0 16.0 TECHNICAL DATA

3.0 - 26 KM/ER40 30.5 40 M50 1.5 8 38.0 17.0

12 - 34 KM/ER50 38.0 50 M64 2 8 48.0 24.0

0.5 - 5 ER 8M 5.2 8 M10 0.75 8 13.0 7.5
17.0 10.0
0.5 - 7 ER11M 7.5 11 M13 0.75 8 22.0 13.0
26.5 13.5
0.5 - 10 ER16M 10.5 16 M19 1 8 29.0 13.0

1.0 - 13 ER20M 13.5 20 M24 1 8

1.0 - 16 ER25M 18.0 25 M30 1 8
