JINYOUNG TOOL TECH

TECHNICAL DATA

TAP SHANK DIMENSIONS (JIS)

Thread Size Uni ed Whithorh Shank Shank
Tap Tap Size Square

M3 NO5,No6 4 3.2

M4 M4.5 54
M5 M5.5 5.5 4.5

M6 U 14 W 14 6 4.5

U 5 16 W 5 16 6.1 5

M8 M7 6.2 5

M10 M9 U 38 W 38 7 5.5
M12 M11 U 7 16 W 7 16 8 6
8.5 6.5
M16 M14 M15 U 12 W 12 9 7
U 9 16 W 9 16 10.5 8
U 58 W 58 12 9
12.5 10

M17 13 10

M18 U 3 4 W 3 4 14 11
15 12
M20

M22 U 78 W 78 17 13
M25 19 15
M24

M27 M26 U1 W1 20 15

M28 21 17

U1 1 8 W1 1 8 22 17
23 17
M30

M32 U1 1 4 W1 1 4 24 19
25 19
TECHNICAL DATA M33

M35 M34 U1 3 8 W1 3 8 26 21
M38 28 21
M36

M39 M40 U1 1 2 W1 1 2 30 23
M45 U1 3 4 W1 5 8 32 26
M42 W1 3 4 35 26
M48 W1 7 8 38 29

TAPERPIPETHREAD& STARIGHT PIPETHREAD (JIS)

PT PS PF Shank Shank
Size Square
18 18 18
14 14 14 8 6
38 38 38 11 9
12 12 12 14 11
58 18 14
34 34 34 19 15
78 23 17
1 1 24 19
1 18 1 26 21
1 14 1 14 1 18 28 21
1 38 1 38 1 14 32 26
1 12 1 12 1 38 35 26
1 12 38 38

134 JIN YOUNG
