2 Flutes Ball End Mills for Heavy Cuts

2

Endmills for various work materials(~HRc52), prehardened E series
steel , carbon steel, mold steel.
Good wear resistance by high quality Si-based PVD coating.
Suitable shape is designed for tooling in wide areas.
Maximize the manufacturing cost saving with low price of products.
Minimize fracturing by high TRS fine(0.5 ) WC grade.

0.005 0.01 0.015 D Size D Tolerance
0.1 ~ 2.5R 3 ~ 6R 8R 0.2 ~ 5 +0 ~ -0.01mm
6 ~ 12 -0.005 ~ -0.015mm
-0.01 ~ -0.02mm
16

mm

Order Number Diameter Length Overall Shank
of cut Length Dia
2HCBE 002 004 S04 RD L1 L d
2HCBE 003 006 S04
2HCBE 004 008 S04 0.1R X 0.2 0.4 40 4
2HCBE 005 010 S04 0.15R X 0.3 0.6 40 4
2HCBE 006 012 S04 0.2R X 0.4 0.8 40 4
2HCBE 007 014 S04 0.25R X 0.5 1 45 4
2HCBE 008 016 S04 0.3R X 0.6 1.2 45 4
2HCBE 009 018 S04 0.35R X 0.7 1.4 45 4
2HCBE 010 025 S04 0.4R X 0.8 1.6 45 4
2HCBE 010 025 S06 0.45R X 0.9 1.8 45 4
2HCBE 012 030 S04 0.5R X 1 2.5 50 4
2HCBE 015 040 S04 0.5R X 1 2.5 50 6
2HCBE 015 040 S06 0.6R X 1.2 3 50 4
2HCBE 020 050 S04 0.75R X 1.5 4 50 4
2HCBE 020 050 S06 0.75R X 1.5 4 50 6
2HCBE 025 050 S04 1R X 2 5 50 4
2HCBE 025 050 S06 1R X 2 5 50 6
2HCBE 030 060 S04 1.25R X 2.5 5 50 4
2HCBE 030 060 S06 1.25R X 2.5 5 50 6
2HCBE 030 060 060 1.5R X 3 6 50 4
2HCBE 040 080 S04 1.5R X 3 6 50 6
2HCBE 040 080 080 1.5R X 3 6 60 6
2HCBE 040 080 S06 2R X 4 8 50 4
2HCBE 040 080 070 2R X 4 8 80 4
2HCBE 050 100 S06 2R X 4 8 50 6
2HCBE 050 120 S06 2R X 4 8 70 6
2HCBE 060 100 050 2.5R X 5 10 50 6
2HCBE 060 100 060 2.5R X 5 12 80 6
2HCBE 060 120 080 3R X 6 10 50 6
2HCBE 060 120 100 3R X 6 10 60 6
2HCBE 080 120 060 3R X 6 12 80 6
2HCBE 080 140 080 3R X 6 12 100 6
2HCBE 080 140 100 4R X 8 12 60 8
2HCBE 100 150 075 4R X 8 14 80 8
2HCBE 100 180 100 4R X 8 14 100 8
2HCBE 120 180 080 5R X 10 15 75 10
2HCBE 120 220 110 5R X 10 18 100 10
2HCBE 160 300 110 6R X 12 18 80 12
6R X 12 22 110 12
8R X 16 30 110 16
