6 Flutes High Speed Corner Radius Cutter

6

HARD series Cutter for pre-hardened and hardened steel (HRc50~62)
Good wear resistance by Si-based PVD coating.
Designed for low speed with high feed condition.
Suitable for heavy duty and roughing application.
Minimize fracturing at high feed by high TRS fine WC grade.

D Size D Tolerance

6 ~ 12 -0.005 ~ -0.015mm

0.005 0.01 0.015 16 ~ 20 -0.01 ~ -0.02mm
R0.5 R1 ~ 1.5 R2
mm

Order Number Diameter Length Overall Shank
of cut Length Dia
6RCU 060 005 060 DR L1
6RCU 060 005 080 Ld
6RCU 060 010 060 6 X R0.5 12
6RCU 060 010 080 6 X R0.5 12 60 6
6RCU 080 005 060 6 X R1 12 80 6
6RCU 080 005 090 6 X R1 12 60 6
6RCU 080 010 060 8 X R0.5 16 80 6
6RCU 080 010 090 8 X R0.5 16 60 8
6RCU 080 020 060 8 X R1 16 90 8
6RCU 080 020 090 8 X R1 16 60 8
6RCU 100 005 070 8 X R2 16 90 8
6RCU 100 005 100 8 X R2 16 60 8
6RCU 100 010 070 10 X R0.5 20 90 8
6RCU 100 010 100 10 X R0.5 20 70 10
6RCU 100 020 070 10 X R1 20 100 10
6RCU 100 020 100 10 X R1 20 70 10
6RCU 120 005 080 10 X R2 20 100 10
6RCU 120 005 110 10 X R2 20 70 10
6RCU 120 010 080 12 X R0.5 25 100 10
6RCU 120 010 110 12 X R0.5 25 80 12
6RCU 120 020 080 12 X R1 25 110 12
6RCU 120 020 110 12 X R1 25 80 12
6RCU 160 005 160 12 X R2 25 110 12
6RCU 160 005 200 12 X R2 25 80 12
6RCU 160 010 160 16 X R0.5 35 110 12
6RCU 160 010 200 16 X R0.5 35 160 16
6RCU 160 015 160 16 X R1 35 200 16
6RCU 160 015 200 16 X R1 35 160 16
6RCU 160 020 160 16 X R1.5 35 200 16
6RCU 160 020 200 16 X R1.5 35 160 16
6RCU 200 005 150 16 X R2 35 200 16
6RCU 200 005 200 16 X R2 35 160 16
6RCU 200 010 150 20 X R0.5 40 200 16
6RCU 200 010 200 20 X R0.5 40 150 20
6RCU 200 015 150 20 X R1 40 200 20
6RCU 200 015 200 20 X R1 40 150 20
6RCU 200 020 150 20 X R1.5 40 200 20
6RCU 200 020 200 20 X R1.5 40 150 20
20 X R2 40 200 20
20 X R2 40 150 20
200 20
