4 Flutes High Speed Corner Radius Cutter
4
Cutter for pre-hardened and hardened steel (HRc50~62) HARD series
Good wear resistance by Si-based PVD coating.
Designed for low speed with high feed condition.
Suitable for heavy duty and roughing application.
Minimize fracturing at high feed by high TRS fine WC grade.
0.005 0.01 0.015 D Size D Tolerance
R2 ~ 3 1~5 +0 ~ -0.01mm
6 ~ 12 -0.005 ~ -0.015mm
16 -0.01 ~ -0.02mm
R0.2 ~ 0.5 R1 ~ 1.5 mm
Order Number Diameter Length Effective Overall Shank
DR of cut Length Length Dia
4RCU 010 002 025
4RCU 015 005 040 L1 L2 L d
4RCU 020 005 060
4RCU 030 005 080 1 X R0.2 1 2.5 50 4
4RCU 040 005 120
4RCU 040 005 160 1.5 X R0.5 1.5 4 50 4
4RCU 040 010 120
4RCU 040 010 160 2 X R0.5 2 6 50 6
4RCU 050 005 150
4RCU 050 010 150 3 X R0.5 3 8 50 6
4RCU 060 003 150
4RCU 060 005 150 4 X R0.5 4 12 60 6
4RCU 060 010 150
4RCU 060 015 150 4 X R0.5 4 16 60 6
4RCU 080 003 160
4RCU 080 005 160 4 X R1 4 12 60 6
4RCU 080 005 200
4RCU 080 005 300 4 X R1 4 16 60 6
4RCU 080 010 160
4RCU 080 010 200 5 X R0.5 5 15 60 6
4RCU 080 010 300
4RCU 080 020 160 5 X R1 5 15 60 6
4RCU 080 020 200
4RCU 080 020 300 6 X R0.3 6 15 60 6
4RCU 100 003 200
4RCU 100 005 200 6 X R0.5 6 15 60 6
4RCU 100 005 250
4RCU 100 005 300 6 X R1 6 15 60 6
4RCU 100 010 200
4RCU 100 010 250 6 X R1.5 6 15 60 6
4RCU 100 010 300
4RCU 100 020 200 8 X R0.3 8 16 60 8
4RCU 100 020 250
4RCU 100 020 300 8 X R0.5 8 16 60 8
4RCU 120 005 250
4RCU 120 005 300 8 X R0.5 8 20 80 8
4RCU 120 005 350
4RCU 120 010 250 8 X R0.5 8 30 110 8
4RCU 120 010 300
4RCU 120 010 350 8 X R1 8 16 60 8
4RCU 120 020 250
4RCU 120 020 300 8 X R1 8 20 80 8
4RCU 120 020 350
4RCU 120 030 250 8 X R1 8 30 110 8
4RCU 160 010 300
4RCU 160 010 400 8 X R2 8 16 60 8
4RCU 160 020 300
4RCU 160 020 400 8 X R2 8 20 80 8
8 X R2 8 30 110 8
10 X R0.3 10 20 70 10
10 X R0.5 10 20 70 10
10 X R0.5 10 25 90 10
10 X R0.5 10 30 120 10
10 X R1 10 20 70 10
10 X R1 10 25 90 10
10 X R1 10 30 120 10
10 X R2 10 20 70 10
10 X R2 10 25 90 10
10 X R2 10 30 120 10
12 X R0.5 12 25 80 12
12 X R0.5 12 30 100 12
12 X R0.5 12 35 130 12
12 X R1 12 25 80 12
12 X R1 12 30 100 12
12 X R1 12 35 130 12
12 X R2 12 25 80 12
12 X R2 12 30 100 12
12 X R2 12 35 130 12
12 X R3 12 25 80 12
16 X R1 16 30 110 16
16 X R1 16 40 160 16
16 X R2 16 30 110 16
16 X R2 16 40 160 16
