4 Flutes High Speed 45 Helix End Mills for Heavy Cuts

4 45

E series Endmills for various work materials(~HRc52), prehardened
steel , carbon steel, mold steel.
Good wear resistance by high quality Si-based PVD coating.
Suitable shape is designed for tooling in wide areas.
45 degree helix design for high speed, feed condition.
Minimize fracturing by high TRS fine(0.5 ) WC grade.

0 0.01 0.01 0.025 0.015 0.03 D Size D Tolerance
1~5 +0 ~ -0.01mm
6 ~ 12 -0.01 ~ -0.025mm
14 ~16 -0.015 ~ -0.03mm

1~ 5 6~ 12 14~ 16 Shield Edge mm

Order Number Diameter Length Overall Shank
of cut Length Dia
4HEME 010 025 S04 D L1 L d
4HEME 010 035 S04
4HEME 012 030 S04 1 2.5 40 4
4HEME 015 040 S04 1 3.5 40 4
4HEME 015 060 S04 1.2 3 40 4
4HEME 020 050 S04 1.5 4 40 4
4HEME 020 080 S04 1.5 6 40 4
4HEME 030 080 S06 2 5 40 4
4HEME 030 120 S06 2 8 45 4
4HEME 040 110 S06 3 8 45 6
4HEME 040 160 S06 3 12 50 6
4HEME 050 130 S06 4 11 45 6
4HEME 050 180 S06 4 16 55 6
4HEME 060 130 S06 5 13 50 6
4HEME 060 200 S06 5 18 60 6
4HEME 080 200 S08 6 13 50 6
4HEME 080 250 S08 6 20 60 6
4HEME 080 300 S08 8 20 60 8
4HEME 100 220 S10 8 25 70 8
4HEME 100 300 S10 8 30 75 8
4HEME 100 400 S10 10 22 70 10
4HEME 120 260 S12 10 30 80 10
4HEME 120 400 S12 10 40 90 10
4HEME 120 500 S12 12 26 75 12
4HEME 140 300 S14 12 40 90 12
4HEME 140 500 S14 12 50 100 12
4HEME 160 350 S16 14 30 80 14
4HEME 160 500 S16 14 50 110 14
16 35 90 16
16 50 110 16
