2 Flutes Corner Radius End Mills for Heavy Cuts

2

Endmills for various work materials(~HRc52), pre-hardened E series
steel , carbon steel, mold steel.
Good wear resistance by high quality Si-based PVD coating.
Designed for minimizing edge chipping by corner R shape.
Various corner R and overall length for wide range application.
Maximize the manufacturing cost saving with low price of products.
Minimize fracturing by high TRS fine(0.5 ) WC grade.

0.005 0.01 0.015 0 0.01 0.005 0.015 D Size D Tolerance
2R 1~5 +0 ~ -0.01mm
6 ~ 12 -0.005 ~ -0.015mm

0.1 ~ 0.5R 1 ~ 1.5R 1~ 5 6~ 12 mm

Order Number Diameter Length Overall Shank Order Number Diameter Length Overall Shank
of cut Length Dia 2NCRE 120 020 110 DR of cut Length Dia
2NCRE 010 001 S04 DR L1 L d L1 L d
2NCRE 010 002 S04 12 X R2
2NCRE 010 003 S04 1 X R0.1 3 50 4 26 110 12
2NCRE 015 001 S04 1 X R0.2 3 50 4
2NCRE 015 002 S04 1 X R0.3 3 50 4
2NCRE 015 003 S04 1.5 X R0.1 4 50 4
2NCRE 015 005 S04 1.5 X R0.2 4 50 4
2NCRE 020 001 S04 1.5 X R0.3 4 50 4
2NCRE 020 002 S04 1.5 X R0.5 4 50 4
2NCRE 020 003 S04 2 X R0.1 6 50 4
2NCRE 020 005 S04 2 X R0.2 6 50 4
2NCRE 025 001 S04 2 X R0.3 6 50 4
2NCRE 025 002 S04 2 X R0.5 6 50 4
2NCRE 025 003 S04 2.5 X R0.1 6 50 4
2NCRE 025 005 S04 2.5 X R0.2 6 50 4
2NCRE 030 001 S06 2.5 X R0.3 6 50 4
2NCRE 030 002 S06 2.5 X R0.5 6 50 4
2NCRE 030 003 S06 3 X R0.1 8 60 6
2NCRE 030 005 S06 3 X R0.2 8 60 6
2NCRE 030 010 S06 3 X R0.3 8 60 6
2NCRE 040 001 S04 3 X R0.5 8 60 6
2NCRE 040 001 S06 3 X R1 8 60 6
2NCRE 040 002 S04 4 X R0.1 10 50 4
2NCRE 040 002 S06 4 X R0.1 10 70 6
2NCRE 040 003 S04 4 X R0.2 10 50 4
2NCRE 040 003 S06 4 X R0.2 10 70 6
2NCRE 040 005 S04 4 X R0.3 10 50 4
2NCRE 040 005 S06 4 X R0.3 10 70 6
2NCRE 040 010 S04 4 X R0.5 10 50 4
2NCRE 040 010 S06 4 X R0.5 10 70 6
2NCRE 050 001 S06 4 X R1 10 50 4
2NCRE 050 002 S06 4 X R1 10 70 6
2NCRE 050 003 S06 5 X R0.1 13 75 6
2NCRE 050 005 S06 5 X R0.2 13 75 6
2NCRE 050 010 S06 5 X R0.3 13 75 6
2NCRE 060 002 080 5 X R0.5 13 75 6
2NCRE 060 003 080 5 X R1 13 75 6
2NCRE 060 005 080 6 X R0.2 13 80 6
2NCRE 060 010 080 6 X R0.3 13 80 6
2NCRE 080 003 090 6 X R0.5 13 80 6
2NCRE 080 005 090 6 X R1 13 80 6
2NCRE 080 010 090 8 X R0.3 19 90 8
2NCRE 100 003 100 8 X R0.5 19 90 8
2NCRE 100 005 100 8 X R1 19 90 8
2NCRE 100 010 100 10 X R0.3 22 100 10
2NCRE 120 003 110 10 X R0.5 22 100 10
2NCRE 120 005 110 10 X R1 22 100 10
2NCRE 120 010 110 12 X R0.3 26 110 12
12 X R0.5 26 110 12
12 X R1 26 110 12
