2 Flutes Rib Ball End Mills for Generality

2

Endmills for various work materials(~HRc52), pre-hardened
steel , carbon steel, mold steel.
Optimum for various work materials by JCRO coating.
High precise edge tolerance.
Minimize fracturing by high TRS fine(0.5 ) WC grade.

G series 0.005 0.01 D Size D Tolerance
0.1 +0 ~ -0.005mm
+0 ~ -0.01mm
0.2 ~ 5 -0.005 ~ -0.015mm
6 ~ 12

0.05 ~ 2.5R 3 ~ 6R mm

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
RD of cut Length Length Dia RD of cut Length Length Dia
2HRBG 001 003 S04 2HRBG 008 060 S04
2HRBG 001 005 S04 L1 L2 L d 2HRBG 008 080 S04 L1 L2 L d
2HRBG 002 005 S04 2HRBG 008 100 S04
2HRBG 002 010 S04 0.05R X 0.1 0.3 - 40 4 2HRBG 008 120 S04 0.4R X 0.8 0.9 6 45 4
2HRBG 002 015 S04 0.05R X 0.1 0.5 - 40 4 2HRBG 008 140 S04 0.4R X 0.8 0.9 8 45 4
2HRBG 002 020 S04 0.1R X 0.2 0.2 0.5 40 4 2HRBG 008 160 S04 0.4R X 0.8 0.9 10 45 4
2HRBG 003 010 S04 0.1R X 0.2 0.2 1 40 4 2HRBG 009 040 S04 0.4R X 0.8 0.9 12 45 4
2HRBG 003 015 S04 0.1R X 0.2 0.2 1.5 40 4 2HRBG 010 020 S04 0.4R X 0.8 0.9 14 45 4
2HRBG 003 020 S04 0.1R X 0.2 0.2 2 40 4 2HRBG 010 020 S06 0.4R X 0.8 0.9 16 45 4
2HRBG 003 030 S04 0.15R X 0.3 0.3 1 40 4 2HRBG 010 030 S04 0.45R X 0.9 1 4 45 4
2HRBG 003 040 S04 0.15R X 0.3 0.3 1.5 40 4 2HRBG 010 030 S06 0.5R X 1 1.2 2 45 4
2HRBG 003 050 S04 0.15R X 0.3 0.3 2 40 4 2HRBG 010 040 S04 0.5R X 1 1.2 2 45 6
2HRBG 004 010 S04 0.15R X 0.3 0.3 3 40 4 2HRBG 010 040 S06 0.5R X 1 1.2 3 45 4
2HRBG 004 020 S04 0.15R X 0.3 0.3 4 40 4 2HRBG 010 050 S04 0.5R X 1 1.2 3 45 6
2HRBG 004 030 S04 0.15R X 0.3 0.3 5 40 4 2HRBG 010 050 S06 0.5R X 1 1.2 4 45 4
2HRBG 004040 S04 0.2R X 0.4 0.5 1 40 4 2HRBG 010 060 S04 0.5R X 1 1.2 4 45 6
2HRBG 004 050 S04 0.2R X 0.4 0.5 2 40 4 2HRBG 010 060 S06 0.5R X 1 1.2 5 45 4
2HRBG 004 060 S04 0.2R X 0.4 0.5 3 40 4 2HRBG 010 080 S04 0.5R X 1 1.2 5 45 6
2HRBG 004 080 S04 0.2R X 0.4 0.5 4 40 4 2HRBG 010 080 S06 0.5R X 1 1.2 6 45 4
2HRBG 004 100 S04 0.2R X 0.4 0.5 5 40 4 2HRBG 010 100 S04 0.5R X 1 1.2 6 45 6
2HRBG 005 010 S04 0.2R X 0.4 0.5 6 40 4 2HRBG 010 100 S06 0.5R X 1 1.2 8 45 4
2HRBG 005 020 S04 0.2R X 0.4 0.5 8 40 4 2HRBG 010 120 S04 0.5R X 1 1.2 8 45 6
2HRBG 005 030 S04 0.2R X 0.4 0.5 10 40 4 2HRBG 010 120 S06 0.5R X 1 1.2 10 50 4
2HRBG 005 040 S04 0.25R X 0.5 0.6 1 45 4 2HRBG 010 140 S04 0.5R X 1 1.2 10 50 6
2HRBG 005 050 S04 0.25R X 0.5 0.6 2 45 4 2HRBG 010 140 S06 0.5R X 1 1.2 12 50 4
2HRBG 005 060 S04 0.25R X 0.5 0.6 3 45 4 2HRBG 010 160 S04 0.5R X 1 1.2 12 50 6
2HRBG 005 080 S04 0.25R X 0.5 0.6 4 45 4 2HRBG 010 160 S06 0.5R X 1 1.2 14 50 4
2HRBG 005 100 S04 0.25R X 0.5 0.6 5 45 4 2HRBG 010 180 S04 0.5R X 1 1.2 14 50 6
2HRBG 005 120 S04 0.25R X 0.5 0.6 6 45 4 2HRBG 010 180 S06 0.5R X 1 1.2 16 50 4
2HRBG 005 140 S04 0.25R X 0.5 0.6 8 45 4 2HRBG 010 200 S04 0.5R X 1 1.2 16 55 6
2HRBG 006 010 S04 0.25R X 0.5 0.6 10 45 4 2HRBG 010 200 S06 0.5R X 1 1.2 18 50 4
2HRBG 006 020 S04 0.25R X 0.5 0.6 12 45 4 2HRBG 010 220 S04 0.5R X 1 1.2 18 60 6
2HRBG 006 030 S04 0.25R X 0.5 0.6 14 45 4 2HRBG 010 220 S06 0.5R X 1 1.2 20 50 4
2HRBG 006 040 S04 0.3R X 0.6 0.7 1 45 4 2HRBG 010 250 S04 0.5R X 1 1.2 20 60 6
2HRBG 006 050 S04 0.3R X 0.6 0.7 2 45 4 2HRBG 012 040 S04 0.5R X 1 1.2 22 60 4
2HRBG 006 060 S04 0.3R X 0.6 0.7 3 45 4 2HRBG 012 040 S06 0.5R X 1 1.2 22 65 6
2HRBG 006 080 S04 0.3R X 0.6 0.7 4 45 4 2HRBG 012 060 S04 0.5R X 1 1.2 25 60 4
2HRBG 006 100 S04 0.3R X 0.6 0.7 5 45 4 2HRBG 012 060 S06 0.6R X 1.2 1.4 4 45 4
2HRBG 006 120 S04 0.3R X 0.6 0.7 6 45 4 2HRBG 012 080 S04 0.6R X 1.2 1.4 4 45 6
2HRBG 006 140 S04 0.3R X 0.6 0.7 8 45 4 2HRBG 012 080 S06 0.6R X 1.2 1.4 6 45 4
2HRBG 006 160 S04 0.3R X 0.6 0.7 10 45 4 2HRBG 012 100 S04 0.6R X 1.2 1.4 6 45 6
2HRBG 007 020 S04 0.3R X 0.6 0.7 12 45 4 2HRBG 012 100 S06 0.6R X 1.2 1.4 8 45 4
2HRBG 007 040 S04 0.3R X 0.6 0.7 14 45 4 2HRBG 012 120 S04 0.6R X 1.2 1.4 8 45 6
2HRBG 007 080 S04 0.3R X 0.6 0.7 16 45 4 2HRBG 012 120 S06 0.6R X 1.2 1.4 10 50 4
2HRBG 007 100 S04 0.35R X 0.7 0.8 2 45 4 2HRBG 012 160 S04 0.6R X 1.2 1.4 10 50 6
2HRBG 007 120 S04 0.35R X 0.7 0.8 4 45 4 2HRBG 012 160 S06 0.6R X 1.2 1.4 12 50 4
2HRBG 008 020 S04 0.35R X 0.7 0.8 8 45 4 2HRBG 012 200 S04 0.6R X 1.2 1.4 12 50 6
2HRBG 008 040 S04 0.35R X 0.7 0.8 10 45 4 2HRBG 012 200 S06 0.6R X 1.2 1.4 16 50 4
0.35R X 0.7 0.8 12 45 4 0.6R X 1.2 1.4 16 55 6
0.4R X 0.8 0.9 2 45 4 0.6R X 1.2 1.4 20 50 4
0.4R X 0.8 0.9 4 45 4 0.6R X 1.2 1.4 20 60 6
