2 Flutes Rib End Mills for Generality

2

Endmills for various work materials(~HRc52), pre-hardened
steel , carbon steel, mold steel.
Optimum for various work materials by JCRO coating.
High precise edge tolerance.
Minimize fracturing by high TRS fine(0.5 ) WC grade.

G series 0 0.05 0 0.01 0.01 0.025 D Size D Tolerance
0.1 0.2 ~ 5 6 ~ 12 0.1 +0 ~ -0.05mm
+0 ~ -0.01mm
0.2 ~ 5 -0.01 ~ -0.025mm
6 ~ 12
mm
Shield Edge

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia of cut Length Length Dia
2HREG 001 003 S04 D L1 L2 L d 2HREG 008 080 S04 D L1 L2 L d
2HREG 001 005 S04 2HREG 008 100 S04
2HREG 002 005 S04 0.1 0.3 - 40 4 2HREG 008 120 S04 0.8 0.9 8 45 4
2HREG 002 010 S04 0.1 0.5 - 40 4 2HREG 008 140 S04 0.8 0.9 10 45 4
2HREG 002 015 S04 0.2 0.3 0.5 40 4 2HREG 009 060 S04 0.8 0.9 12 45 4
2HREG 002 020 S04 0.2 0.2 1 40 4 2HREG 009 080 S04 0.8 0.9 14 45 4
2HREG 003 010 S04 0.2 0.2 1.5 40 4 2HREG 009 100 S04 0.9 1 6 45 4
2HREG 003 015 S04 0.2 0.2 2 40 4 2HREG 010 020 S04 0.9 1 8 45 4
2HREG 003 020 S04 0.3 0.3 1 40 4 2HREG 010 030 S04 0.9 1 10 45 4
2HREG 003 030 S04 0.3 0.3 1.5 40 4 2HREG 010 040 S04 1 1.2 2 45 4
2HREG 003 040 S04 0.3 0.3 2 40 4 2HREG 010 050 S04 1 1.2 3 45 4
2HREG 003 050 S04 0.3 0.3 3 40 4 2HREG 010 060 S04 1 1.2 4 45 4
2HREG 004 010 S04 0.3 0.3 4 40 4 2HREG 010 080 S04 1 1.2 5 45 4
2HREG 004 020 S04 0.3 0.3 5 40 4 2HREG 010 100 S04 1 1.2 6 45 4
2HREG 004 030 S04 0.4 0.5 1 40 4 2HREG 010 120 S04 1 1.2 8 45 4
2HREG 004 040 S04 0.4 0.5 2 40 4 2HREG 010 140 S04 1 1.2 10 50 4
2HREG 004 050 S04 0.4 0.5 3 40 4 2HREG 010 160 S04 1 1.2 12 50 4
2HREG 004 060 S04 0.4 0.5 4 40 4 2HREG 010 180 S04 1 1.2 14 50 4
2HREG 004 080 S04 0.4 0.5 5 40 4 2HREG 010 200 S04 1 1.2 16 50 4
2HREG 004 100 S04 0.4 0.5 6 40 4 2HREG 010 250 S04 1 1.2 18 50 4
2HREG 005 020 S04 0.4 0.5 8 40 4 2HREG 010 300 S04 1 1.2 20 50 4
2HREG 005 030 S04 0.4 0.5 10 40 4 2HREG 012 040 S04 1 1.2 25 60 4
2HREG 005 040 S04 0.5 0.6 2 45 4 2HREG 012 060 S04 1 1.2 30 70 4
2HREG 005 050 S04 0.5 0.6 3 45 4 2HREG 012 080 S04 1.2 1.4 4 45 4
2HREG 005 060 S04 0.5 0.6 4 45 4 2HREG 012 100 S04 1.2 1.4 6 45 4
2HREG 005 080 S04 0.5 0.6 5 45 4 2HREG 012 120 S04 1.2 1.4 8 45 4
2HREG 005 100 S04 0.5 0.6 6 45 4 2HREG 012 160 S04 1.2 1.4 10 50 4
2HREG 005 120 S04 0.5 0.6 8 45 4 2HREG 012 200 S04 1.2 1.4 12 50 4
2HREG 005 140 S04 0.5 0.6 10 45 4 2HREG 012 250 S04 1.2 1.4 16 50 4
2HREG 006 020 S04 0.5 0.6 12 45 4 2HREG 012 300 S04 1.2 1.4 20 50 4
2HREG 006 030 S04 0.5 0.6 14 45 4 2HREG 014 060 S04 1.2 1.4 25 60 4
2HREG 006 040 S04 0.6 0.7 2 45 4 2HREG 014 080 S04 1.2 1.4 30 70 4
2HREG 006 050 S04 0.6 0.7 3 45 4 2HREG 014 100 S04 1.4 1.6 6 45 4
2HREG 006 060 S04 0.6 0.7 4 45 4 2HREG 014 140 S04 1.4 1.6 8 45 4
2HREG 006 080 S04 0.6 0.7 5 45 4 2HREG 014 160 S04 1.4 1.6 10 50 4
2HREG 006 100 S04 0.6 0.7 6 45 4 2HREG 014 200 S04 1.4 1.6 14 50 4
2HREG 006 120 S04 0.6 0.7 8 45 4 2HREG 015 040 S04 1.4 1.6 16 50 4
2HREG 006 140 S04 0.6 0.7 10 45 4 2HREG 015 060 S04 1.4 1.6 20 50 4
2HREG 006 160 S04 0.6 0.7 12 45 4 2HREG 015 080 S04 1.5 1.8 4 45 4
2HREG 007 020 S04 0.6 0.7 14 45 4 2HREG 015 100 S04 1.5 1.8 6 45 4
2HREG 007 040 S04 0.6 0.7 16 45 4 2HREG 015 120 S04 1.5 1.8 8 45 4
2HREG 007 060 S04 0.7 0.8 2 45 4 2HREG 015 140 S04 1.5 1.8 10 50 4
2HREG 007 080 S04 0.7 0.8 4 45 4 2HREG 015 160 S04 1.5 1.8 12 50 4
2HREG 007 100 S04 0.7 0.8 6 45 4 2HREG 015 180 S04 1.5 1.8 14 50 4
2HREG 007 120 S04 0.7 0.8 8 45 4 2HREG 015 200 S04 1.5 1.8 16 50 4
2HREG 008 020 S04 0.7 0.8 10 45 4 2HREG 015 250 S04 1.5 1.8 18 50 4
2HREG 008 040 S04 0.7 0.8 12 45 4 2HREG 015 300 S04 1.5 1.8 20 50 4
2HREG 008 060 S04 0.8 0.9 2 45 4 2HREG 016 100 S04 1.5 1.8 25 60 4
0.8 0.9 4 45 4 1.5 1.8 30 70 4
97 JJ TOOLS 0.8 0.9 6 45 4 1.6 1.9 10 50 4
