4 Flutes Standard Length End Mills for Generality

4

Endmills for various work materials(~HRc52), pre-hardened
steel , carbon steel, mold steel.
Optimum for various work materials by JCRO coating.
High precise edge tolerance.
Minimize fracturing by high TRS fine(0.5 ) WC grade.

0 0.01 0.01 0.025 0.015 0.03 D Size D Tolerance G series
0.8 ~ 5.5 6 ~ 12 14 ~ 20 0.8 ~ 5.5 +0 ~ -0.01mm
-0.01 ~ -0.025mm
6 ~ 12 -0.015 ~ -0.03mm
14 ~ 20

Shield Edge mm

Order Number Diameter Length Overall Shank Order Number Diameter Length Overall Shank
of cut Length Dia of cut Length Dia
4HCEG 008 020 S04 D L1 L d 4HCEG 070 160 S08 D L1 L d
4HCEG 010 010 S04 4HCEG 075 160 S08
4HCEG 010 025 S04 0.8 2 40 4 4HCEG 080 080 S08 7 16 60 8
4HCEG 010 025 S06 1 1 40 4 4HCEG 080 190 S08 7.5 16 60 8
4HCEG 010 025 060 1 2.5 40 4 4HCEG 080 200 S08 8 8 50 8
4HCEG 010 025 080 1 2.5 40 6 4HCEG 085 190 S10 8 19 60 8
4HCEG 010 040 S06 1 2.5 60 6 4HCEG 090 190 S10 8 20 70 8
4HCEG 012 012 S04 1 2.5 80 6 4HCEG 095 190 S10 8.5 19 70 10
4HCEG 012 030 S04 1 4 50 6 4HCEG 100 100 S10 9 19 70 10
4HCEG 012 030 S06 1.2 1.2 40 4 4HCEG 100 220 S10 9.5 19 70 10
4HCEG 012 030 060 1.2 3 40 4 4HCEG 100 250 S10 10 10 60 10
4HCEG 012 060 S06 1.2 3 40 6 4HCEG 105 220 S12 10 22 70 10
4HCEG 015 015 S04 1.2 3 60 6 4HCEG 110 220 S12 10 25 75 10
4HCEG 015 040 S04 1.5 6 50 6 4HCEG 115 220 S12 10.5 22 75 12
4HCEG 015 040 S06 1.5 1.5 40 4 4HCEG 120 120 S12 11 22 75 12
4HCEG 015 040 060 1.5 4 40 4 4HCEG 120 260 S12 11.5 22 75 12
4HCEG 015 040 080 1.5 4 40 6 4HCEG 120 300 S12 12 12 65 12
4HCEG 020 020 S04 1.5 4 60 6 4HCEG 140 260 S14 12 26 75 12
4HCEG 020 060 S04 1.5 4 80 6 4HCEG 140 260 S16 12 30 80 12
4HCEG 020 060 S06 2 2 40 4 4HCEG 160 350 S16 14 26 80 14
4HCEG 020 060 060 2 6 40 4 4HCEG 160 400 S16 14 26 85 16
4HCEG 020 060 100 2 6 40 6 4HCEG 180 350 S18 16 35 100 16
4HCEG 025 080 S04 2 6 60 6 4HCEG 200 400 S20 16 40 100 16
4HCEG 025 080 S06 2 6 100 6 4HCEG 200 450 S20 18 35 100 18
4HCEG 025 080 070 2.5 8 45 4 20 40 100 20
4HCEG 025 080 100 2.5 8 45 6 20 45 100 20
4HCEG 030 080 S03 2.5 8 70 6
4HCEG 030 080 S04 2.5 8 100 6
4HCEG 030 080 S06 3 8 45 3
4HCEG 030 080 070 3 8 45 4
4HCEG 030 080 100 3 8 45 6
4HCEG 035 100 S06 3 8 70 6
4HCEG 040 040 S04 3 8 100 6
4HCEG 040 110 S04 3.5 10 45 6
4HCEG 040 110 S06 4 4 40 4
4HCEG 040 110 070 4 11 45 4
4HCEG 040 110 100 4 11 45 6
4HCEG 045 110 S06 4 11 70 6
4HCEG 050 130 S06 4 11 100 6
4HCEG 050 130 080 4.5 11 45 6
4HCEG 050 130 100 5 13 50 6
4HCEG 055 130 S06 5 13 80 6
4HCEG 060 060 S06 5 13 100 6
4HCEG 060 130 S06 5.5 13 50 6
4HCEG 060 130 080 6 6 45 6
4HCEG 060 130 100 6 13 50 6
4HCEG 060 150 S06 6 13 80 6
4HCEG 065 160 S08 6 13 100 6
6 15 60 6
6.5 16 60 8

www.jjtools.co.kr 102
