2 Flutes Rib Corner Radius End Mills for Generality

2

mm

G series Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia of cut Length Length Dia
2CREG 030 010 400 DR L1 L2 L d 2CREG 050 005 300 DR L1 L2 L d
2CREG 040 001 050 2CREG 050 005 400
2CREG 040 001 070 3 X R1 3.6 40 80 6 2CREG 050 005 500 5 X R0.5 6 30 70 6
2CREG 040 001 120 4 X R0.1 4.8 12 50 4 2CREG 050 010 150 5 X R0.5 6 40 80 6
2CREG 040 001 160 4 X R0.1 4.8 20 70 4 2CREG 050 010 250 5 X R0.5 6 50 100 6
2CREG 040 001 200 4 X R0.1 4.8 12 50 6 2CREG 050 010 300 5 X R1 6 15 55 6
2CREG 040 001 250 4 X R0.1 4.8 16 55 6 2CREG 050 010 400 5 X R1 6 25 70 6
2CREG 040 001 300 4 X R0.1 4.8 20 60 6 2CREG 050 010 500 5 X R1 6 30 70 6
2CREG 040 001 350 4 X R0.1 4.8 25 65 6 2CREG 060 001 200 5 X R1 6 40 80 6
2CREG 040 001 400 4 X R0.1 4.8 30 70 6 2CREG 060 001 400 5 X R1 6 50 100 6
2CREG 040 001 450 4 X R0.1 4.8 35 75 6 2CREG 060 002 200 6 X R0.1 7 20 60 6
2CREG 040 001 500 4 X R0.1 4.8 40 80 6 2CREG 060 002 400 6 X R0.1 7 40 90 6
2CREG 040 002 050 4 X R0.1 4.8 45 90 6 2CREG 060 003 200 6 X R0.2 7 20 60 6
2CREG 040 002 070 4 X R0.1 4.8 50 100 6 2CREG 060 003 400 6 X R0.2 7 40 90 6
2CREG 040 002 120 4 X R0.2 4.8 12 50 4 2CREG 060 005 200 6 X R0.3 7 20 60 6
2CREG 040 002 160 4 X R0.2 4.8 20 70 4 2CREG 060 005 400 6 X R0.3 7 40 90 6
2CREG 040 002 200 4 X R0.2 4.8 12 50 6 2CREG 060 010 200 6 X R0.5 7 20 60 6
2CREG 040 002 250 4 X R0.2 4.8 16 55 6 2CREG 060 010 400 6 X R0.5 7 40 90 6
2CREG 040 002 300 4 X R0.2 4.8 20 60 6 2CREG 060 015 200 6 X R1 7 20 60 6
2CREG 040 002 350 4 X R0.2 4.8 25 65 6 2CREG 060 015 400 6 X R1 7 40 90 6
2CREG 040 002 400 4 X R0.2 4.8 30 70 6 2CREG 080 002 220 6 X R1.5 7 20 60 6
2CREG 040 002 450 4 X R0.2 4.8 35 75 6 2CREG 080 002 400 6 X R1.5 7 40 90 6
2CREG 040 002 500 4 X R0.2 4.8 40 80 6 2CREG 080 003 220 8 X R0.2 9 22 65 8
2CREG 040 003 050 4 X R0.2 4.8 45 90 6 2CREG 080 003 400 8 X R0.2 9 40 100 8
2CREG 040 003 070 4 X R0.2 4.8 50 100 6 2CREG 080 005 220 8 X R0.3 9 22 65 8
2CREG 040 003 120 4 X R0.3 4.8 12 50 4 2CREG 080 005 400 8 X R0.3 9 40 100 8
2CREG 040 003 160 4 X R0.3 4.8 20 70 4 2CREG 080 010 220 8 X R0.5 9 22 65 8
2CREG 040 003 200 4 X R0.3 4.8 12 50 6 2CREG 080 010 400 8 X R0.5 9 40 100 8
2CREG 040 003 250 4 X R0.3 4.8 16 55 6 2CREG 080 015 220 8 X R1 9 22 65 8
2CREG 040 003 300 4 X R0.3 4.8 20 60 6 2CREG 080 015 400 8 X R1 9 40 100 8
2CREG 040 003 350 4 X R0.3 4.8 25 65 6 2CREG 100 002 240 8 X R1.5 9 22 65 8
2CREG 040 003 400 4 X R0.3 4.8 30 70 6 2CREG 100 002 450 8 X R1.5 9 40 100 8
2CREG 040 003 450 4 X R0.3 4.8 35 75 6 2CREG 100 003 240 10 X R0.2 11 24 70 10
2CREG 040 003 500 4 X R0.3 4.8 40 80 6 2CREG 100 003 450 10 X R0.2 11 45 100 10
2CREG 040 005 050 4 X R0.3 4.8 45 90 6 2CREG 100 005 240 10 X R0.3 11 24 70 10
2CREG 040 005 070 4 X R0.3 4.8 50 100 6 2CREG 100 005 450 10 X R0.3 11 45 100 10
2CREG 040 005 120 4 X R0.5 4.8 12 50 4 2CREG 100 010 240 10 X R0.5 11 24 70 10
2CREG 040 005 160 4 X R0.5 4.8 20 70 4 2CREG 100 010 450 10 X R0.5 11 45 100 10
2CREG 040 005 200 4 X R0.5 4.8 12 50 6 2CREG 100 015 240 10 X R1 11 24 70 10
2CREG 040 005 250 4 X R0.5 4.8 16 55 6 2CREG 100 015 450 10 X R1 11 45 100 10
2CREG 040 005 300 4 X R0.5 4.8 20 60 6 2CREG 100 020 240 10 X R1.5 11 24 70 10
2CREG 040 005 350 4 X R0.5 4.8 25 65 6 2CREG 100 020 450 10 X R1.5 11 45 100 10
2CREG 040 005 400 4 X R0.5 4.8 30 70 6 2CREG 120 002 260 10 X R2 11 24 70 10
2CREG 040 005 450 4 X R0.5 4.8 35 75 6 2CREG 120 002 500 10 X R2 11 45 100 10
2CREG 040 005 500 4 X R0.5 4.8 40 80 6 2CREG 120 003 260 12 X R0.2 13 26 80 12
2CREG 040 010 050 4 X R0.5 4.8 45 90 6 2CREG 120 003 500 12 X R0.2 13 50 110 12
2CREG 040 010 070 4 X R0.5 4.8 50 100 6 2CREG 120 005 260 12 X R0.3 13 26 80 12
2CREG 040 010 120 4 X R1 4.8 12 50 4 2CREG 120 005 500 12 X R0.3 13 50 110 12
2CREG 040 010 160 4 X R1 4.8 20 70 4 2CREG 120 010 260 12 X R0.5 13 26 80 12
2CREG 040 010 200 4 X R1 4.8 12 50 6 2CREG 120 010 500 12 X R0.5 13 50 110 12
2CREG 040 010 250 4 X R1 4.8 16 55 6 2CREG 120 015 260 12 X R1 13 26 80 12
2CREG 040 010 300 4 X R1 4.8 20 60 6 2CREG 120 015 500 12 X R1 13 50 110 12
2CREG 040 010 350 4 X R1 4.8 25 65 6 2CREG 120 020 260 12 X R1.5 13 26 80 12
2CREG 040 010 400 4 X R1 4.8 30 70 6 2CREG 120 020 500 12 X R1.5 13 50 110 12
2CREG 040 010 450 4 X R1 4.8 35 75 6 2CREG 120 030 260 12 X R2 13 26 80 12
2CREG 040 010 500 4 X R1 4.8 40 80 6 2CREG 120 030 500 12 X R2 13 50 110 12
2CREG 050 002 150 4 X R1 4.8 45 90 6 2CREG 160 005 110 12 X R3 13 26 80 12
2CREG 050 002 250 4 X R1 4.8 50 100 6 2CREG 160 005 160 12 X R3 13 50 110 12
2CREG 050 002 300 5 X R0.2 6 15 55 6 2CREG 160 010 110 16 X R0.5 20 35 110 16
2CREG 050 002 400 5 X R0.2 6 25 70 6 2CREG 160 010 160 16 X R0.5 20 35 160 16
2CREG 050 002 500 5 X R0.2 6 30 70 6 16 X R1 20 35 110 16
2CREG 050 005 150 5 X R0.2 6 40 80 6 16 X R1 20 35 160 16
2CREG 050 005 250 5 X R0.2 6 50 100 6
5 X R0.5 6 15 55 6
5 X R0.5 6 25 70 6
