2 Flutes Rib Corner Radius End Mills for Generality

2

mm

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank G series
of cut Length Length Dia of cut Length Length Dia
2CREG 015 001 060 DR L1 L2 L d 2CREG 020 005 160 DR L1 L2 L d
2CREG 015 001 080 2CREG 020 005 200
2CREG 015 001 100 1.5 X R0.1 1.8 6 45 4 2CREG 020 005 250 2 X R0.5 2.4 16 50 4
2CREG 015 001 120 1.5 X R0.1 1.8 8 45 4 2CREG 020 005 300 2 X R0.5 2.4 20 50 4
2CREG 015 001 160 1.5 X R0.1 1.8 10 50 4 2CREG 025 001 100 2 X R0.5 2.4 25 60 4
2CREG 015 001 200 1.5 X R0.1 1.8 12 50 4 2CREG 025 001 160 2 X R0.5 2.4 30 70 4
2CREG 015 001 220 1.5 X R0.1 1.8 16 50 4 2CREG 025 001 200 2.5 X R0.1 3 10 50 4
2CREG 015 001 250 1.5 X R0.1 1.8 20 50 4 2CREG 025 001 250 2.5 X R0.1 3 16 50 4
2CREG 015 002 040 1.5 X R0.1 1.8 22 60 4 2CREG 025 001 300 2.5 X R0.1 3 20 50 4
2CREG 015 002 060 1.5 X R0.1 1.8 25 60 4 2CREG 025 002 100 2.5 X R0.1 3 25 60 4
2CREG 015 002 080 1.5 X R0.2 1.8 4 45 4 2CREG 025 002 160 2.5 X R0.1 3 30 70 4
2CREG 015 002 100 1.5 X R0.2 1.8 6 45 4 2CREG 025 002 200 2.5 X R0.2 3 10 50 4
2CREG 015 002 120 1.5 X R0.2 1.8 8 45 4 2CREG 025 002 250 2.5 X R0.2 3 16 50 4
2CREG 015 002 160 1.5 X R0.2 1.8 10 50 4 2CREG 025 002 300 2.5 X R0.2 3 20 50 4
2CREG 015 002 200 1.5 X R0.2 1.8 12 50 4 2CREG 025 003 100 2.5 X R0.2 3 25 60 4
2CREG 015 002 220 1.5 X R0.2 1.8 16 50 4 2CREG 025 003 160 2.5 X R0.2 3 30 70 4
2CREG 015 002 250 1.5 X R0.2 1.8 20 50 4 2CREG 025 003 200 2.5 X R0.3 3 10 50 4
2CREG 015 003 040 1.5 X R0.2 1.8 22 60 4 2CREG 025 003 250 2.5 X R0.3 3 16 50 4
2CREG 015 003 060 1.5 X R0.2 1.8 25 60 4 2CREG 025 003 300 2.5 X R0.3 3 20 50 4
2CREG 015 003 080 1.5 X R0.3 1.8 4 45 4 2CREG 025 005 100 2.5 X R0.3 3 25 60 4
2CREG 015 003 100 1.5 X R0.3 1.8 6 45 4 2CREG 025 005 160 2.5 X R0.3 3 30 70 4
2CREG 015 003 120 1.5 X R0.3 1.8 8 45 4 2CREG 025 005 200 2.5 X R0.5 3 10 50 4
2CREG 015 003 160 1.5 X R0.3 1.8 10 50 4 2CREG 025 005 250 2.5 X R0.5 3 16 50 4
2CREG 015 003 200 1.5 X R0.3 1.8 12 50 4 2CREG 025 005 300 2.5 X R0.5 3 20 50 4
2CREG 015 003 220 1.5 X R0.3 1.8 16 50 4 2CREG 030 001 100 2.5 X R0.5 3 25 60 4
2CREG 015 003 250 1.5 X R0.3 1.8 20 50 4 2CREG 030 001 120 2.5 X R0.5 3 30 70 4
2CREG 015 005 040 1.5 X R0.3 1.8 22 60 4 2CREG 030 001 160 3 X R0.1 3.6 10 50 6
2CREG 015 005 060 1.5 X R0.3 1.8 25 60 4 2CREG 030 001 200 3 X R0.1 3.6 12 50 6
2CREG 015 005 080 1.5 X R0.5 1.8 4 45 4 2CREG 030 001 250 3 X R0.1 3.6 16 55 6
2CREG 015 005 100 1.5 X R0.5 1.8 6 45 4 2CREG 030 001 300 3 X R0.1 3.6 20 60 6
2CREG 015 005 120 1.5 X R0.5 1.8 8 45 4 2CREG 030 001 350 3 X R0.1 3.6 25 65 6
2CREG 015 005 160 1.5 X R0.5 1.8 10 50 4 2CREG 030 001 400 3 X R0.1 3.6 30 70 6
2CREG 015 005 200 1.5 X R0.5 1.8 12 50 4 2CREG 030 002 100 3 X R0.1 3.6 35 75 6
2CREG 015 005 220 1.5 X R0.5 1.8 16 50 4 2CREG 030 002 120 3 X R0.1 3.6 40 80 6
2CREG 015 005 250 1.5 X R0.5 1.8 20 50 4 2CREG 030 002 160 3 X R0.2 3.6 10 50 6
2CREG 020 001 060 1.5 X R0.5 1.8 22 60 4 2CREG 030 002 200 3 X R0.2 3.6 12 50 6
2CREG 020 001 080 1.5 X R0.5 1.8 25 60 4 2CREG 030 002 250 3 X R0.2 3.6 16 55 6
2CREG 020 001 100 2 X R0.1 2.4 6 45 4 2CREG 030 002 300 3 X R0.2 3.6 20 60 6
2CREG 020 001 120 2 X R0.1 2.4 8 45 4 2CREG 030 002 350 3 X R0.2 3.6 25 65 6
2CREG 020 001 160 2 X R0.1 2.4 10 50 4 2CREG 030 002 400 3 X R0.2 3.6 30 70 6
2CREG 020 001 200 2 X R0.1 2.4 12 50 4 2CREG 030 003 100 3 X R0.2 3.6 35 75 6
2CREG 020 001 250 2 X R0.1 2.4 16 50 4 2CREG 030 003 120 3 X R0.2 3.6 40 80 6
2CREG 020 001 300 2 X R0.1 2.4 20 50 4 2CREG 030 003 160 3 X R0.3 3.6 10 50 6
2CREG 020 002 060 2 X R0.1 2.4 25 60 4 2CREG 030 003 200 3 X R0.3 3.6 12 50 6
2CREG 020 002 080 2 X R0.1 2.4 30 70 4 2CREG 030 003 250 3 X R0.3 3.6 16 55 6
2CREG 020 002 100 2 X R0.2 2.4 6 45 4 2CREG 030 003 300 3 X R0.3 3.6 20 60 6
2CREG 020 002 120 2 X R0.2 2.4 8 45 4 2CREG 030 003 350 3 X R0.3 3.6 25 65 6
2CREG 020 002 160 2 X R0.2 2.4 10 50 4 2CREG 030 003 400 3 X R0.3 3.6 30 70 6
2CREG 020 002 200 2 X R0.2 2.4 12 50 4 2CREG 030 005 100 3 X R0.3 3.6 35 75 6
2CREG 020 002 250 2 X R0.2 2.4 16 50 4 2CREG 030 005 120 3 X R0.3 3.6 40 80 6
2CREG 020 002 300 2 X R0.2 2.4 20 50 4 2CREG 030 005 160 3 X R0.5 3.6 10 50 6
2CREG 020 003 060 2 X R0.2 2.4 25 60 4 2CREG 030 005 200 3 X R0.5 3.6 12 50 6
2CREG 020 003 080 2 X R0.2 2.4 30 70 4 2CREG 030 005 250 3 X R0.5 3.6 16 55 6
2CREG 020 003 100 2 X R0.3 2.4 6 45 4 2CREG 030 005 300 3 X R0.5 3.6 20 60 6
2CREG 020 003 120 2 X R0.3 2.4 8 45 4 2CREG 030 005 350 3 X R0.5 3.6 25 65 6
2CREG 020 003 160 2 X R0.3 2.4 10 50 4 2CREG 030 005 400 3 X R0.5 3.6 30 70 6
2CREG 020 003 200 2 X R0.3 2.4 12 50 4 2CREG 030 010 100 3 X R0.5 3.6 35 75 6
2CREG 020 003 250 2 X R0.3 2.4 16 50 4 2CREG 030 010 120 3 X R0.5 3.6 40 80 6
2CREG 020 003 300 2 X R0.3 2.4 20 50 4 2CREG 030 010 160 3 X R1 3.6 10 50 6
2CREG 020 005 060 2 X R0.3 2.4 25 60 4 2CREG 030 010 200 3 X R1 3.6 12 50 6
2CREG 020 005 080 2 X R0.3 2.4 30 70 4 2CREG 030 010 250 3 X R1 3.6 16 55 6
2CREG 020 005 100 2 X R0.5 2.4 6 45 4 2CREG 030 010 300 3 X R1 3.6 20 60 6
2CREG 020 005 120 2 X R0.5 2.4 8 45 4 2CREG 030 010 350 3 X R1 3.6 25 65 6
2 X R0.5 2.4 10 50 4 3 X R1 3.6 30 70 6
2 X R0.5 2.4 12 50 4 3 X R1 3.6 35 75 6
