4Flutes Long Length End Mills for Generality

4

Endmills for various work materials(~HRc52), pre-hardened
steel , carbon steel, mold steel.
Optimum for various work materials by JCRO coating.
Improve tool performance by even run-out and tolerance control.
Various flute and overall length design for covering wide range
applications as well as high efficiency machining.
Minimize edge chipping by improving corner strength.

G series 0 0.01 0.01 0.025 0.015 0.03 D Size D Tolerance
1~ 5 6 ~ 12 14 ~ 25 1~5 +0 ~ -0.01mm
6 ~ 12 -0.01 ~ -0.025mm
-0.015 ~ -0.03mm
14 ~ 25

Shield Edge mm

Order Number Diameter Length Overall Shank Order Number Diameter Length Overall Shank
of cut Length Dia D of cut Length Dia
4LEMG 010 030 S06 D L1 L d 4LEMG 200 500 160 L1 L d
4LEMG 010 050 S06 4LEMG 200 600 S20 20
4LEMG 015 060 S06 1 3 60 6 4LEMG 200 1000 S20 20 50 160 20
4LEMG 015 080 S06 1 5 60 6 4LEMG 250 750 S25 20 60 130 20
4LEMG 020 080 S06 1.5 6 60 6 25 100 200 20
4LEMG 020 100 S06 1.5 8 60 6 75 160 25
4LEMG 030 100 S06 2 8 60 6
4LEMG 030 150 S06 2 10 60 6
4LEMG 030 200 S06 3 10 70 6
4LEMG 030 250 S06 3 15 70 6
4LEMG 040 120 S06 3 20 70 6
4LEMG 040 150 S04 3 25 70 6
4LEMG 040 150 S06 4 12 70 6
4LEMG 040 200 S04 4 15 70 4
4LEMG 040 200 S06 4 15 70 6
4LEMG 040 250 S06 4 20 70 4
4LEMG 040 300 S06 4 20 70 6
4LEMG 050 200 S06 4 25 70 6
4LEMG 050 250 S06 4 30 75 6
4LEMG 050 300 S06 5 20 70 6
4LEMG 060 200 S06 5 25 75 6
4LEMG 060 200 100 5 30 80 6
4LEMG 060 250 S06 6 20 75 6
4LEMG 060 300 S06 6 20 100 6
4LEMG 060 350 S06 6 25 75 6
4LEMG 080 250 S08 6 30 80 6
4LEMG 080 250 100 6 35 80 6
4LEMG 080 300 S08 8 25 75 8
4LEMG 080 350 S08 8 25 100 8
4LEMG 080 400 S08 8 30 80 8
4LEMG 080 450 S08 8 35 90 8
4LEMG 100 300 S10 8 40 90 8
4LEMG 100 300 110 8 45 100 8
4LEMG 100 350 S10 10 30 80 10
4LEMG 100 400 S10 10 30 110 10
4LEMG 100 500 S10 10 35 90 10
4LEMG 100 600 S10 10 40 90 10
4LEMG 120 300 S12 10 50 100 10
4LEMG 120 350 110 10 60 110 10
4LEMG 120 400 S12 12 30 90 12
4LEMG 120 500 S12 12 35 110 12
4LEMG 120 600 S12 12 40 100 12
4LEMG 120 700 S12 12 50 100 12
4LEMG 140 500 S14 12 60 110 12
4LEMG 160 400 160 12 70 130 12
4LEMG 160 550 S16 14 50 110 14
4LEMG 160 700 S16 16 40 160 16
New 4LEMG 180 800 160 16 55 120 16
16 70 130 16
18 80 160 18
