2 Flutes Long Length End Mills for Generality

2

Endmills for various work materials(~HRc52), pre-hardened
steel , carbon steel, mold steel.
Optimum for various work materials by JCRO coating.
Improve tool performance by even run-out and tolerance control.
Various flute and overall length design for covering wide range
applications as well as high efficiency machining.
Minimize edge chipping by improving corner strength.

0 0.01 0.01 0.025 0.015 0.03 D Size D Tolerance
1~ 5 6 ~ 12 14 ~ 25 1~5 +0 ~ -0.01mm
6 ~ 12 -0.01 ~ -0.025mm
-0.015 ~ -0.03mm
14 ~ 25

G series Shield Edge mm

Order Number Diameter Length Overall Shank Order Number Diameter Length Overall Shank
of cut Length Dia of cut Length Dia
2LEMG 010 030 S06 D L1 L d 2LEMG 160 400 160 D L1 L d
2LEMG 010 050 S06 2LEMG 160 550 S16
2LEMG 010 070 S06 1 3 60 6 2LEMG 160 700 S16 16 40 160 16
2LEMG 010 100 S06 1 5 60 6 2LEMG 160 800 S16 16 55 120 16
2LEMG 010 150 S06 1 7 60 6 2LEMG 200 500 160 16 70 130 16
2LEMG 015 060 S06 1 10 60 6 2LEMG 200 600 S20 16 80 160 16
2LEMG 015 075 S06 1 15 60 6 2LEMG 200 1000 S20 20 50 160 20
2LEMG 015 100 S06 1.5 6 60 6 2LEMG 250 750 S25 20 60 130 20
2LEMG 015 150 S06 1.5 7.5 60 6 20 100 200 20
2LEMG 015 200 S06 1.5 10 60 6 25 75 160 25
2LEMG 020 060 S06 1.5 15 60 6
2LEMG 020 100 S06 1.5 20 60 6
2LEMG 020 150 S06 2 6 60 6
2LEMG 020 200 S06 2 10 60 6
2LEMG 030 120 S06 2 15 60 6
2LEMG 030 150 S06 2 20 60 6
2LEMG 030 200 S06 3 12 70 6
2LEMG 030 250 S06 3 15 70 6
2LEMG 030 300 S06 3 20 70 6
2LEMG 040 150 S06 3 25 70 6
2LEMG 040 200 S06 3 30 70 6
2LEMG 040 300 S06 4 15 70 6
2LEMG 050 200 S06 4 20 70 6
2LEMG 050 250 S06 4 30 75 6
2LEMG 050 300 S06 5 20 70 6
2LEMG 060 200 S06 5 25 75 6
2LEMG 060 200 100 5 30 80 6
2LEMG 060 250 S06 6 20 75 6
2LEMG 060 300 S06 6 20 100 6
2LEMG 080 250 S08 6 25 75 6
2LEMG 080 250 100 6 30 80 6
2LEMG 080 300 S08 8 25 75 8
2LEMG 080 350 S08 8 25 100 8
2LEMG 080 400 S08 8 30 80 8
2LEMG 080 500 S08 8 35 80 8
2LEMG 100 300 S10 8 40 90 8
2LEMG 100 300 110 8 50 100 8
2LEMG 100 350 S10 10 30 80 10
2LEMG 100 400 S10 10 30 110 10
2LEMG 100 500 S10 10 35 90 10
2LEMG 100 600 S10 10 40 90 10
2LEMG 120 300 S12 10 50 100 10
2LEMG 120 350 110 10 60 110 10
2LEMG 120 400 S12 12 30 90 12
2LEMG 120 500 S12 12 35 110 12
2LEMG 120 600 S12 12 40 100 12
2LEMG 120 700 S12 12 50 100 12
2LEMG 140 500 S14 12 60 110 12
12 70 130 12
14 50 110 14
