2 Flutes Corner Radius End Mills for Generality

2

Endmills for various work materials(~HRc52), pre-hardened
steel , carbon steel, mold steel.
Optimum for various work materials by JCRO coating.
High precise edge tolerance.
Designed for minimizing edge chipping by corner R shape.
Various corner R and overall length for wide range application.
Minimize fracturing by high TRS fine(0.5 ) WC grade.

G series 0.005 0.01 0.015 D Size D Tolerance
R2 ~ 5 0.4 ~ 5 +0 ~ -0.01mm
6 ~ 12 -0.005 ~ -0.015mm

R0.05 ~ 0.5 R1 ~ 1.5 mm

Order Number Diameter Length Overall Shank Order Number Diameter Length Overall Shank
of cut Length Dia of cut Length Dia
2NCRG 004 0005 S04 DR L1 L d 2NCRG 040 005 080 DR L1 L d
2NCRG 004 001 S04 2NCRG 040 005 S06
2NCRG 005 0005 S04 0.4 X R0.05 0.8 45 4 2NCRG 040 010 060 4 X R0.5 9 80 4
2NCRG 005 001 S04 0.4 X R0.1 0.8 45 4 2NCRG 040 010 080 4 X R0.5 10 70 6
2NCRG 006 0005 S04 0.5 X R0.05 1 45 4 2NCRG 040 010 S06 4 X R1 9 60 4
2NCRG 006 001 S04 0.5 X R0.1 1 45 4 2NCRG 050 001 S06 4 X R1 9 80 4
2NCRG 006 002 S04 0.6 X R0.05 1.2 45 4 2NCRG 050 002 S06 4 X R1 10 70 6
2NCRG 007 0005 S04 0.6 X R0.1 1.2 45 4 2NCRG 050 003 S06 5 X R0.1 13 75 6
2NCRG 007 001 S04 0.6 X R0.2 1.2 45 4 2NCRG 050 005 S06 5 X R0.2 13 75 6
2NCRG 007 002 S04 0.7 X R0.05 1.4 45 4 2NCRG 050 010 S06 5 X R0.3 13 75 6
2NCRG 008 0005 S04 0.7 X R0.1 1.4 45 4 2NCRG 060 001 060 5 X R0.5 13 75 6
2NCRG 008 001 S04 0.7 X R0.2 1.4 45 4 2NCRG 060 001 090 5 X R1 13 75 6
2NCRG 008 002 S04 0.8 X R0.05 1.6 45 4 2NCRG 060 002 060 6 X R0.1 11 60 6
2NCRG 009 0005 S04 0.8 X R0.1 1.6 45 4 2NCRG 060 002 090 6 X R0.1 13 90 6
2NCRG 009 001 S04 0.8 X R0.2 1.6 45 4 2NCRG 060 003 060 6 X R0.2 11 60 6
2NCRG 010 001 S04 0.9 X R0.05 1.8 45 4 2NCRG 060 003 090 6 X R0.2 13 90 6
2NCRG 010 002 S04 0.9 X R0.1 1.8 45 4 2NCRG 060 005 060 6 X R0.3 11 60 6
2NCRG 010 003 S04 1 X R0.1 2.5 45 4 2NCRG 060 005 090 6 X R0.3 13 90 6
2NCRG 012 001 S04 1 X R0.2 2.5 45 4 2NCRG 060 010 060 6 X R0.5 11 60 6
2NCRG 012 002 S04 1 X R0.3 2.5 45 4 2NCRG 060 010 090 6 X R0.5 13 90 6
2NCRG 012 003 S04 1.2 X R0.1 3.2 45 4 2NCRG 060 015 060 6 X R1 11 60 6
2NCRG 015 001 S04 1.2 X R0.2 3.2 45 4 2NCRG 060 015 090 6 X R1 13 90 6
2NCRG 015 002 S04 1.2 X R0.3 3.2 45 4 2NCRG 060 020 060 6 X R1.5 11 60 6
2NCRG 015 003 S04 1.5 X R0.1 4 45 4 2NCRG 060 020 090 6 X R1.5 13 90 6
2NCRG 015 005 S04 1.5 X R0.2 4 45 4 2NCRG 060 025 090 6 X R2 11 60 6
2NCRG 020 001 S04 1.5 X R0.3 4 45 4 2NCRG 080 001 070 6 X R2 13 90 6
2NCRG 020 002 S04 1.5 X R0.5 4 45 4 2NCRG 080 001 100 6 X R2.5 13 90 6
2NCRG 020 003 S04 2 X R0.1 6 45 4 2NCRG 080 002 070 8 X R0.1 16 70 8
2NCRG 020 005 S04 2 X R0.2 6 45 4 2NCRG 080 002 100 8 X R0.1 19 100 8
2NCRG 025 001 S04 2 X R0.3 6 45 4 2NCRG 080 003 070 8 X R0.2 16 70 8
2NCRG 025 002 S04 2 X R0.5 6 45 4 2NCRG 080 003 100 8 X R0.2 19 100 8
2NCRG 025 003 S04 2.5 X R0.1 6 50 4 2NCRG 080 005 070 8 X R0.3 16 70 8
2NCRG 025 005 S04 2.5 X R0.2 6 50 4 2NCRG 080 005 100 8 X R0.3 19 100 8
2NCRG 030 001 S06 2.5 X R0.3 6 50 4 2NCRG 080 005 120 8 X R0.5 16 70 8
2NCRG 030 002 S06 2.5 X R0.5 6 50 4 2NCRG 080 010 070 8 X R0.5 19 100 8
2NCRG 030 003 S06 3 X R0.1 8 60 6 2NCRG 080 010 100 8 X R0.5 19 120 8
2NCRG 030 005 S06 3 X R0.2 8 60 6 2NCRG 080 010 120 8 X R1 16 70 8
2NCRG 030 010 S06 3 X R0.3 8 60 6 2NCRG 080 015 070 8 X R1 19 100 8
2NCRG 040 001 060 3 X R0.5 8 60 6 2NCRG 080 015 100 8 X R1 19 120 8
2NCRG 040 001 080 3 X R1 8 60 6 2NCRG 080 020 070 8 X R1.5 16 70 8
2NCRG 040 001 S06 4 X R0.1 9 60 4 2NCRG 080 020 100 8 X R1.5 19 100 8
2NCRG 040 002 060 4 X R0.1 9 80 4 2NCRG 080 025 100 8 X R2 16 70 8
2NCRG 040 002 080 4 X R0.1 10 70 6 2NCRG 080 030 100 8 X R2 19 100 8
2NCRG 040 002 S06 4 X R0.2 9 60 4 2NCRG 080 035 100 8 X R2.5 19 100 8
2NCRG 040 003 060 4 X R0.2 9 80 4 2NCRG 100 001 075 8 X R3 19 100 8
2NCRG 040 003 080 4 X R0.2 10 70 6 2NCRG 100 001 100 8 X R3.5 19 100 8
2NCRG 040 003 S06 4 X R0.3 9 60 4 2NCRG 100 002 075 10 X R0.1 19 75 10
2NCRG 040 005 060 4 X R0.3 9 80 4 2NCRG 100 002 100 10 X R0.1 22 100 10
4 X R0.3 10 70 6 10 X R0.2 19 75 10
4 X R0.5 9 60 4 10 X R0.2 22 100 10
