4 Flutes Corner Radius End Mills for Generality

4

mm G series

Order Number Diameter Length Overall Shank
of cut Length Dia
4NCRG 100 025 120 DR L1 L d
4NCRG 100 030 100
4NCRG 120 002 080 10 X R2.5 22 120 10
4NCRG 120 002 110 10 X R3 22 100 10
4NCRG 120 003 080 12 X R0.2 22 80 12
4NCRG 120 003 110 12 X R0.2 26 110 12
4NCRG 120 005 080 12 X R0.3 22 80 12
4NCRG 120 005 110 12 X R0.3 26 110 12
4NCRG 120 005 130 12 X R0.5 22 80 12
4NCRG 120 010 080 12 X R0.5 26 110 12
4NCRG 120 010 110 12 X R0.5 26 130 12
4NCRG 120 010 130 12 X R1 22 80 12
4NCRG 120 015 080 12 X R1 26 110 12
4NCRG 120 015 110 12 X R1 26 130 12
4NCRG 120 015 130 12 X R1.5 22 80 12
4NCRG 120 020 080 12 X R1.5 26 110 12
4NCRG 120 020 110 12 X R1.5 26 130 12
4NCRG 120 020 130 12 X R2 22 80 12
4NCRG 120 025 080 12 X R2 26 110 12
4NCRG 120 025 110 12 X R2 26 130 12
4NCRG 120 025 130 12 X R2.5 22 80 12
4NCRG 120 030 080 12 X R2.5 26 110 12
4NCRG 120 030 110 12 X R2.5 26 130 12
4NCRG 120 030 130 12 X R3 22 80 12
4NCRG 120 035 110 12 X R3 26 110 12
4NCRG 120 040 110 12 X R3 26 130 12
4NCRG 160 005 110 12 X R3.5 26 110 12
4NCRG 160 005 160 12 X R4 26 110 12
4NCRG 160 010 110 16 X R0.5 35 110 16
4NCRG 160 010 160 16 X R0.5 35 160 16
16 X R1 35 110 16
16 X R1 35 160 16
