3 Flutes Diamond Coated Taper Neck Ball End Mills for Graphite

3

Endmills for Graphite, reinforced plastic, carbon fiber,
Non-ferrous and non-metallic materials.
Excellent wear resistance by applying qualified CVD diamond coating.
Wide range products prepared for various work shape and excellent
performance.

D Size D Tolerance
1~4 +0 ~ -0.02mm

0.01 mm
0.5 ~ 6R
FOR GRAPHITE Diameter Angle Length Effective Overall Shank
Order Number of cut Length Length Dia
RD 0 30 L1 d
3TBD 010 003 300 0 30 L2 L
3TBD 010 003 400 0.5R X 1 0 30 3 4
3TBD 010 003 500 0.5R X 1 3 30 100 4
3TBD 010 010 300 0.5R X 1 1 3 40 100 4
3TBD 010 010 400 0.5R X 1 1 3 50 100 4
3TBD 010 010 500 0.5R X 1 1 3 30 100 4
3TBD 010 010 600 0.5R X 1 1 3 40 100 4
3TBD 015 003 300 0.5R X 1 0 30 3 50 100 4
3TBD 015 003 400 0.75R X 1.5 0 30 4 60 100 4
3TBD 015 003 500 0.75R X 1.5 0 30 4 30 100 4
3TBD 015 010 400 0.75R X 1.5 1 4 40 100 4
3TBD 015 010 500 0.75R X 1.5 1 4 50 100 4
3TBD 015 010 600 0.75R X 1.5 1 4 40 100 4
3TBD 020 003 400 0.75R X1.5 0 30 4 50 100 4
3TBD 020 003 500 1R X 2 0 30 5 60 100 4
3TBD 020 003 600 1R X 2 0 30 5 40 130 4
3TBD 020 010 500 1R X 2 1 5 50 130 4
3TBD 020 010 600 1R X 2 1 5 60 130 4
3TBD 020 010 700 1R X 2 1 5 50 130 4
3TBD 030 003 600 1R X 2 0 30 5 60 130 4
3TBD 030 003 800 1.5R X 3 0 30 6 70 130 6
3TBD 030 010 700 1.5R X 3 1 6 60 150 6
3TBD 030 010 900 1.5R X 3 1 6 80 150 6
3TBD 040 003 800 1.5R X 3 0 30 6 70 150 6
3TBD 040 003 1000 2R X 4 0 30 8 90 150 6
3TBD 040 010 1000 2R X 4 1 8 80 150 6
2R X 4 8 100 150 6
100 150
