3 Flutes Diamond Coated End Mills for Graphite

3

Endmills for Graphite, reinforced plastic, carbon fiber,
Non-ferrous and non-metallic materials.
Excellent wear resistance by applying qualified CVD diamond coating.
Wide range products prepared for various work shape and excellent
performance.

D Size D Tolerance
1 ~ 12 +0 ~ -0.02mm

0 0.02 Shield Edge mm
1~ 12

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia of cut Length Length Dia
3DEM 010 030 S04
New 3DEM 010 050 S04 D L1 L2 L d D L1 L2 L d
New 3DEM 010 100 S04
New 3DEM 010 150 S04 1 3 - 45 4 FOR GRAPHITE
1 3 5 45 4
3DEM 015 060 S04 1 3 10 45 4
New 3DEM 015 100 S04 1 3 15 45 4
New 3DEM 015 150 S04 1.5 6 - 60 4
New 3DEM 015 200 S04 1.5 6 10 60 4
1.5 6 15 60 4
3DEM 020 060 S04 1.5 6 20 60 4
3DEM 020 100 S04 2 6 - 45 4
New 3DEM 020 150 S04 2 10 10 60 4
New 3DEM 020 200 S04 2 10 15 60 4
New 3DEM 020 250 S04 2 10 20 60 4
3DEM 030 090 S06 2 10 25 60 4
3DEM 030 150 S03 3 9 9 50 6
3DEM 030 150 S04 3 15 - 60 3
New 3DEM 030 200 S04 3 15 - 60 4
New 3DEM 030 250 S04 3 15 20 60 4
3DEM 040 120 S06 3 15 25 60 4
3DEM 040 200 080 4 12 - 50 6
3DEM 060 180 060 4 20 - 80 6
3DEM 060 250 110 6 18 - 60 6
3DEM 060 250 150 6 25 - 110 6
3DEM 080 240 070 6 25 - 150 6
3DEM 080 350 110 8 24 - 70 8
3DEM 080 350 150 8 35 - 110 8
3DEM 100 250 080 8 35 - 150 8
3DEM 100 400 110 10 25 - 80 10
3DEM 100 500 160 10 40 - 110 10
3DEM 120 250 080 10 50 - 160 10
3DEM 120 450 110 12 25 - 80 12
3DEM 120 550 160 12 45 - 110 12
12 55 - 160 12
