4&6 Flutes Diamond Coated End Mills for Graphite

4&6

Endmills for Graphite, reinforced plastic, carbon fiber,
Non-ferrous and non-metallic materials.
Excellent wear resistance by applying qualified CVD diamond coating.
Wide range products prepared for various work shape and excellent
performance.

D Size D Tolerance
2 ~ 16 +0 ~ -0.02mm

0 0.02 4F 6F Shield Edge mm
2~ 16
Order Number
FOR GRAPHITE Order Number Diameter Length Overall Shank Diameter Length Overall Shank
of cut Length Dia 6DEM 100 400 110 of cut Length Dia
4DEM 020 060 S04 D L1 L d 6DEM 100 400 160 D L1 L d
4DEM 020 100 S04 6DEM 120 450 110
4DEM 030 090 S06 2 6 45 4 6DEM 120 450 160 10 40 110 10
4DEM 030 150 S03 2 10 60 4 6DEM 160 500 110 10 40 160 10
4DEM 030 150 S04 3 9 50 6 6DEM 160 500 160 12 45 110 12
4DEM 040 120 S06 3 15 60 3 6DEM 160 500 200 12 45 160 12
4DEM 040 200 080 3 15 60 4 16 50 110 16
New 4DEM 040 200 100 4 12 50 6 16 50 160 16
4DEM 060 180 060 4 20 80 4 16 50 200 16
4DEM 060 250 110 4 20 100 4
4DEM 060 250 150 6 18 60 6
4DEM 080 240 070 6 25 110 6
4DEM 080 350 110 6 25 150 6
4DEM 080 350 150 8 24 70 8
4DEM 100 250 080 8 35 110 8
4DEM 100 400 110 8 35 150 8
4DEM 100 500 160 10 25 80 10
4DEM 120 250 080 10 40 110 10
4DEM 120 450 110 10 50 160 10
4DEM 120 550 160 12 25 80 12
12 45 110 12
12 55 160 12
