2 Flutes Rib Corner Radius End Mills for Copper
2
Endmills for copper, copper alloy, nonferrous and non-
metallic materials.
JCRO coating provides wear resistance improvement as well as
avoid edge stress in various applications.
Smooth chip outflow by deep chip pocket.
Minimize fracturing by high TRS fine(0.5 ) WC grade.
0.005 0.01 D Size D Tolerance
R0.1 ~ 0.5 R1 ~ 1.5 1~4 +0 ~ -0.01mm
6 ~ 12 -0.005 ~ -0.015mm
mm
Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
DR of cut Length Length Dia DR of cut Length Length Dia
2COR 010 001 040 2COR 020 001 160
2COR 010 001 060 L1 L2 L d 2COR 020 001 200 L1 L2 L d
2COR 010 001 080 2COR 020 001 250
2COR 010 001 100 1 X R0.1 1.5 4 50 4 2COR 020 002 060 2 X R0.1 3 16 50 64 FOR COPPER
2COR 010 001 120 1 X R0.1 1.5 6 50 4 2COR 020 002 100 2 X R0.1 3 20 50 4
2COR 010 001 160 1 X R0.1 1.5 8 50 4 2COR 020 002 120 2 X R0.1 3 25 60 4
2COR 010 001 200 1 X R0.1 1.5 10 50 4 2COR 020 002 160 2 X R0.2 3 6 50 4
2COR 010 002 040 1 X R0.1 1.5 12 50 4 2COR 020 002 200 2 X R0.2 3 10 50 4
2COR 010 002 060 1 X R0.1 1.5 16 50 4 2COR 020 002 250 2 X R0.2 3 12 50 4
2COR 010 002 080 1 X R0.1 1.5 20 50 4 2COR 020 003 060 2 X R0.2 3 16 50 4
2COR 010 002 100 1 X R0.2 1.5 4 50 4 2COR 020 003 100 2 X R0.2 3 20 50 4
2COR 010 002 120 1 X R0.2 1.5 6 50 4 2COR 020 003 120 2 X R0.2 3 25 60 4
2COR 010 002 160 1 X R0.2 1.5 8 50 4 2COR 020 003 160 2 X R0.3 3 6 50 4
2COR 010 002 200 1 X R0.2 1.5 10 50 4 2COR 020 003 200 2 X R0.3 3 10 50 4
2COR 010 003 040 1 X R0.2 1.5 12 50 4 2COR 020 003 250 2 X R0.3 3 12 50 4
2COR 010 003 060 1 X R0.2 1.5 16 50 4 2COR 020 005 060 2 X R0.3 3 16 50 4
2COR 010 003 080 1 X R0.2 1.5 20 50 4 2COR 020 005 100 2 X R0.3 3 20 50 4
2COR 010 003 100 1 X R0.3 1.5 4 50 4 2COR 020 005 120 2 X R0.3 3 25 60 4
2COR 010 003 120 1 X R0.3 1.5 6 50 4 2COR 020 005 140 2 X R0.5 3 6 50 4
2COR 010 003 160 1 X R0.3 1.5 8 50 4 2COR 020 005 160 2 X R0.5 3 10 50 4
2COR 010 003 200 1 X R0.3 1.5 10 50 4 2COR 020 005 200 2 X R0.5 3 12 50 4
2COR 015 001 060 1 X R0.3 1.5 12 50 4 2COR 020 005 250 2 X R0.5 3 14 50 4
2COR 015 001 100 1 X R0.3 1.5 16 50 4 2COR 025 001 060 2 X R0.5 3 16 50 4
2COR 015 001 120 1 X R0.3 1.5 20 50 4 2COR 025 001 100 2 X R0.5 3 20 50 4
2COR 015 001 160 1.5 X R0.1 2 6 50 4 2COR 025 001 120 2 X R0.5 3 25 60 4
2COR 015 001 200 1.5 X R0.1 2 10 50 4 2COR 025 001 160 2.5 X R0.1 3.5 6 50 4
2COR 015 001 250 1.5 X R0.1 2 12 50 4 2COR 025 001 200 2.5 X R0.1 3.5 10 50 4
2COR 015 002 060 1.5 X R0.1 2 16 50 4 2COR 025 001 250 2.5 X R0.1 3.5 12 50 4
2COR 015 002 100 1.5 X R0.1 2 20 50 4 2COR 025 002 060 2.5 X R0.1 3.5 16 50 4
2COR 015 002 120 1.5 X R0.1 2 25 60 4 2COR 025 002 100 2.5 X R0.1 3.5 20 50 4
2COR 015 002 160 1.5 X R0.2 2 6 50 4 2COR 025 002 120 2.5 X R0.1 3.5 25 60 4
2COR 015 002 200 1.5 X R0.2 2 10 50 4 2COR 025 002 160 2.5 X R0.2 3.5 6 50 4
2COR 015 002 250 1.5 X R0.2 2 12 50 4 2COR 025 002 200 2.5 X R0.2 3.5 10 50 4
2COR 015 003 060 1.5 X R0.2 2 16 50 4 2COR 025 002 250 2.5 X R0.2 3.5 12 50 4
2COR 015 003 100 1.5 X R0.2 2 20 50 4 2COR 025 003 060 2.5 X R0.2 3.5 16 50 4
2COR 015 003 120 1.5 X R0.2 2 25 60 4 2COR 025 003 100 2.5 X R0.2 3.5 20 50 4
2COR 015 003 160 1.5 X R0.3 2 6 50 4 2COR 025 003 120 2.5 X R0.2 3.5 25 60 4
2COR 015 003 200 1.5 X R0.3 2 10 50 4 2COR 025 003 160 2.5 X R0.3 3.5 6 50 4
2COR 015 003 250 1.5 X R0.3 2 12 50 4 2COR 025 003 200 2.5 X R0.3 3.5 10 50 4
2COR 015 005 060 1.5 X R0.3 2 16 50 4 2COR 025 003 250 2.5 X R0.3 3.5 12 50 4
2COR 015 005 100 1.5 X R0.3 2 20 50 4 2COR 025 005 060 2.5 X R0.3 3.5 16 50 4
2COR 015 005 120 1.5 X R0.3 2 25 60 4 2COR 025 005 100 2.5 X R0.3 3.5 20 50 4
2COR 015 005 160 1.5 X R0.5 2 6 50 4 2COR 025 005 120 2.5 X R0.3 3.5 25 60 4
2COR 015 005 200 1.5 X R0.5 2 10 50 4 2COR 025 005 160 2.5 X R0.5 3.5 6 50 4
2COR 015 005 250 1.5 X R0.5 2 12 50 4 2COR 025 005 200 2.5 X R0.5 3.5 10 50 4
2COR 020 001 060 1.5 X R0.5 2 16 50 4 2COR 025 005 250 2.5 X R0.5 3.5 12 50 4
2COR 020 001 100 1.5 X R0.5 2 20 50 4 2COR 030 001 100 2.5 X R0.5 3.5 16 50 4
2COR 020 001 120 1.5 X R0.5 2 25 60 4 2COR 030 001 120 2.5 X R0.5 3.5 20 50 4
2 X R0.1 3 6 50 4 2.5 X R0.5 3.5 25 60 4
2 X R0.1 3 10 50 4 3 X R0.1 4 10 55 6
2 X R0.1 3 12 50 4 3 X R0.1 4 12 55 6
