4 Flutes Non Symmetry Corner Radius End Mills for SUS

4 SUS

Endmills for alloy steel, SUS, Ti/Ni base alloy, Inconel
and hard to cut materials.
JCRO coating provides wear resistance improvement as well as
avoid edge stress in various applications.
Strong design for protection against chattering..
Preventing bottom edge chipping by corner R.
Minimize fracturing at high feed by high TRS fine WC grade.

0.005 0.01 0.015 D Size D Tolerance
R2 ~ 3 1 ~ 5.5 +0 ~ -0.01mm
6 ~ 12 -0.005 ~ -0.015mm
16 ~ 20 -0.01 ~ -0.02mm

R0.1 ~ 0.5 R1 ~ 1.5 mm

Order Number Diameter Length Overall Shank Order Number Diameter Length Overall Shank FOR SUS
of cut Length Dia of cut Length Dia
4SUC 010 001 S04 DR L1 L d 4SUC 080 003 S08 DR L1 L d
4SUC 010 002 S04 4SUC 080 005 070
4SUC 012 001 S04 1 X R0.1 2.5 50 4 4SUC 080 005 S08 8 X R0.3 20 80 8
4SUC 012 002 S04 1 X R0.2 2.5 50 4 4SUC 080 010 070 8 X R0.5 16 70 8
4SUC 015 001 S04 1.2 X R0.1 3 50 4 4SUC 080 010 S08 8 X R0.5 20 80 8
4SUC 015 002 S04 1.2 X R0.2 3 50 4 New 4SUC 080 015 S08 8 X R1 16 70 8
4SUC 015 003 S04 1.5 X R0.1 4 50 4 New 4SUC 080 020 S08 8 X R1 20 80 8
4SUC 020 001 S04 1.5 X R0.2 4 50 4 4SUC 085 003 S10 8 X R1.5 20 80 8
4SUC 020 002 S04 1.5 X R0.3 4 50 4 4SUC 090 003 S10 8 X R2 20 80 8
4SUC 020 003 S04 2 X R0.1 6 50 4 4SUC 100 003 070 8.5 X R0.3 22 80 10
4SUC 020 005 S04 2 X R0.2 6 50 4 4SUC 100 003 S10 9 X R0.3 25 80 10
4SUC 025 001 S04 2 X R0.3 6 50 4 4SUC 100 005 070 10 X R0.3 20 70 10
4SUC 025 002 S04 2 X R0.5 6 50 4 4SUC 100 005 S10 10 X R0.3 25 80 10
4SUC 025 003 S04 2.5 X R0.1 7 50 4 4SUC 100 010 070 10 X R0.5 20 70 10
4SUC 030 001 S06 2.5 X R0.2 7 50 4 4SUC 100 010 S10 10 X R0.5 25 80 10
4SUC 030 002 055 2.5 X R0.3 7 50 4 4SUC 100 015 070 10 X R1 20 70 10
4SUC 030 002 S06 3 X R0.1 10 60 6 4SUC 100 015 S10 10 X R1 25 80 10
4SUC 030 003 S06 3 X R0.2 6 55 6 4SUC 100 020 070 10 X R1.5 20 70 10
4SUC 030 005 055 3 X R0.2 10 60 6 4SUC 100 020 S10 10 X R1.5 25 80 10
4SUC 030 005 S06 3 X R0.3 10 60 6 4SUC 100 025 070 10 X R2 20 70 10
4SUC 035 002 S06 3 X R0.5 6 55 6 4SUC 100 025 S10 10 X R2 25 80 10
4SUC 040 001 S06 3 X R0.5 10 60 6 4SUC 100 030 070 10 X R2.5 20 70 10
4SUC 040 002 055 3.5 X R0.2 10 60 6 4SUC 100 030 S10 10 X R2.5 25 80 10
4SUC 040 002 S06 4 X R0.1 12 60 6 New 4SUC 110 005 S12 10 X R3 20 70 10
4SUC 040 003 S06 4 X R0.2 8 55 6 New 4SUC 110 010 S12 10 X R3 25 80 10
4SUC 040 005 055 4 X R0.2 12 60 6 4SUC 120 003 080 11 X R0.5 27 90 12
4SUC 040 005 S06 4 X R0.3 12 60 6 4SUC 120 003 S12 11 X R1 27 90 12
4SUC 040 010 S06 4 X R0.5 8 55 6 4SUC 120 005 080 12 X R0.3 24 80 12
4SUC 045 002 S06 4 X R0.5 12 60 6 4SUC 120 005 S12 12 X R0.3 30 100 12
4SUC 050 002 055 4 X R1 12 60 6 4SUC 120 010 080 12 X R0.5 24 80 12
4SUC 050 002 S06 4.5 X R0.2 14 60 6 4SUC 120 010 S12 12 X R0.5 30 100 12
4SUC 050 003 S06 5 X R0.2 10 55 6 4SUC 120 015 080 12 X R1 24 80 12
4SUC 050 005 055 5 X R0.2 15 60 6 4SUC 120 015 S12 12 X R1 30 100 12
4SUC 050 005 S06 5 X R0.3 15 60 6 4SUC 120 020 080 12 X R1.5 24 80 12
4SUC 050 010 S06 5 X R0.5 10 55 6 4SUC 120 020 S12 12 X R1.5 30 100 12
4SUC 055 002 S06 5 X R0.5 15 60 6 4SUC 120 025 S12 12 X R2 24 80 12
4SUC 060 003 055 5 X R1 15 60 6 4SUC 120 030 080 12 X R2 30 100 12
4SUC 060 003 S06 5.5 X R0.2 15 60 6 4SUC 120 030 S12 12 X R2.5 30 100 12
4SUC 060 005 055 6 X R0.3 12 55 6 New 4SUC 140 005 S14 12 X R3 24 80 12
4SUC 060 005 S06 6 X R0.3 15 60 6 New 4SUC 140 010 S14 12 X R3 30 100 12
4SUC 060 010 055 6 X R0.5 12 55 6 4SUC 160 005 100 14 X R0.5 35 100 14
4SUC 060 010 S06 6 X R0.5 15 60 6 4SUC 160 005 S16 14 X R1 35 100 14
New 4SUC 060 015 S06 6 X R1 12 55 6 4SUC 160 010 100 16 X R0.5 32 100 16
4SUC 065 003 S08 6 X R1 15 60 6 4SUC 160 010 S16 16 X R0.5 42 110 16
4SUC 070 003 S08 6 X R1.5 15 60 6 New 4SUC180 005 S18 16 X R1 32 100 16
New 4SUC 070 005 S08 6.5 X R0.3 18 60 8 New 4SUC180 010 S18 16 X R1 42 110 16
New 4SUC 007 010 S08 7 X R0.3 20 80 8 4SUC 200 005 S20 18 X R0.5 45 110 18
4SUC 080 003 070 7 X R0.5 20 80 8 4SUC 200 010 S20 18 X R1 45 110 18
7 X R1 20 80 8 20 X R0.5 48 110 20
8 X R0.3 16 70 8 20 X R1 48 110 20
