4 Flutes Rib End Mills for SUS

4 SUS

Endmills for alloy steel, SUS, Ti/Ni base alloy, Inconel
and hard to cut materials.
JCRO coating provides wear resistance improvement as well as
avoid edge stress in various applications.
Minimize chattering by unequal flute spacing design.
Excellent work surface finish by 4 flute and deep chip pocket.
Minimize fracturing at high feed by high TRS fine WC grade.

0 0.01 0.01 0.025 0.015 0.03 D Size D Tolerance
1~ 5 6 ~ 12 16 ~ 20 1~5 +0 ~ -0.01mm
6 ~ 12 -0.01 ~ -0.025mm
-0.015 ~ -0.03mm
16 ~ 20
mm
Shield Edge

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia of cut Length Length Dia
4SURE 010 030 S04
4SURE 010 050 S04 D L1 L2 L d D L1 L2 L d
4SURE 015 045 S04
4SURE 015 060 S04 1 1.5 3 50 4 FOR SUS
4SURE 015 080 S04 1 1.5 5 50 4
4SURE 020 060 S04 1.5 2.5 4.5 50 4
4SURE 020 080 S04 1.5 2.5 6 50 4
4SURE 020 100 S04 1.5 2.5 8 50 4
4SURE 020 120 S04 2 3 6 50 4
4SURE 025 075 S04 2 3 8 50 4
4SURE 025 100 S04 2 3 10 50 4
4SURE 025 120 S04 2 3 12 50 4
4SURE 030 090 S06 2.5 4 7.5 50 4
4SURE 030 120 S06 2.5 4 10 50 4
4SURE 030 160 S06 2.5 4 12 50 4
4SURE 030 200 S06 3 4.5 9 60 6
4SURE 040 120 S06 3 4.5 12 60 6
4SURE 040 160 S06 3 4.5 16 60 6
4SURE 040 200 S06 3 4.5 20 60 6
4SURE 040 250 S06 4 6 12 60 6
4SURE 050 150 S06 4 6 16 60 6
4SURE 050 180 100 4 6 20 60 6
4SURE 050 200 S06 4 6 25 65 6
4SURE 050 250 S06 5 7.5 15 60 6
4SURE 050 300 S06 5 7.5 18 100 6
4SURE 060 200 S06 5 7.5 20 60 6
4SURE 060 250 100 5 7.5 25 65 6
4SURE 060 300 S06 5 7.5 30 70 6
4SURE 080 250 S08 6 9 20 60 6
4SURE 080 350 110 6 9 25 100 6
4SURE 080 400 S08 6 9 30 70 6
4SURE 100 300 S10 8 12 25 70 8
4SURE 100 400 120 8 12 35 110 8
4SURE 100 500 S10 8 12 40 80 8
4SURE 120 360 S12 10 15 30 80 10
4SURE 120 500 130 10 15 40 120 10
4SURE 120 600 S12 10 15 50 100 10
4SURE 160 480 S16 12 18 36 90 12
4SURE 160 700 150 12 18 50 130 12
4SURE 160 800 S16 12 18 60 110 12
4SURE 200 600 130 16 24 48 110 16
4SURE 200 1000 160 16 24 70 150 16
16 24 80 130 16
20 30 60 130 20
20 30 100 160 20
