2COR RPM : rev./min Feed : mm/min

Slotting Side Cutting
Copper / Copper Alloys
Material Copper / Copper Alloys

Outside Radius Effective RPM FEED Ap RPM FEED Ap Ap
Diameter Length
1mm R0.1, R0.2 45,000 2,500 Axial Depth 45,000 4,500 Axial Depth Radial Depth
1.5mm R0.1, R0.2 3 40,000 2,000 40,000 3,000
2mm R0.1, R0.2 6 35,000 1,600 0.036 35,000 2,000 0.036 0.2
3mm R0.1, R0.2 10 23,000 1,800 0.03 50,000 6,000 0.03 0.2
R0.1, R0.2 5 26,000 1,600 45,000 5,500 0.2
4mm R0.1, R0.2 8 30,000 1,500 0.025 40,000 4,500 0.025 0.3
R0.1, R0.2 12 35,000 1,800 0.08 45,000 5,000 0.08 0.3
6mm R0.1, R0.2 6 30,000 1,600 0.06 40,000 4,700 0.06 0.3
R0.1, R0.2 10 30,000 1,200 0.05 30,000 3,800 0.04 0.8
8mm R0.2, R0.3 14 30,000 2,200 0.14 40,000 6,500 0.12 0.6
10mm R0.2, R0.3 10 20,000 2,000 0.12 35,000 6,000 0.1 0.4
12mm R0.2, R0.3 16 20,000 2,000 0.08 35,000 6,000 0.06
20 20,000 2,600 0.14 38,000 10,000 0.12 1
R0.5 10 20,000 2,200 0.12 35,000 8,000 0.1 0.6
R0.5 16 20,000 2,200 0.12 35,000 8,000 0.1 0.6
R0.5 20 20,000 2,600 0.14 40,000 8,000 0.12 0.8
R0.2, R0.3 12 15,000 2,400 0.12 32,000 5,000 0.1 0.6
R0.2, R0.3 16 15,000 2,000 0.12 32,000 5,000 0.1 0.6
R0.2, R0.3 20 20,000 2,400 0.5 35,000 10,000 0.18 0.12
R0.5 12 15,000 2,200 0.3 32,000 7,000 0.16 0.1
R0.5 16 15,000 2,200 0.25 32,000 7,000 0.15 0.8
R0.5 20 10,000 1,400 0.5 20,000 5,200 0.3 0.1
R0.3, R0.5 20 10,000 1,200 0.25 20,000 5,000 0.15 0.8
R0.3, R0.5 30 10,000 1,800 0.25 20,000 9,000 0.15 0.8
R1 20 10,000 1,500 0.6 20,000 7,000 0.25 1.2
R1 30 1,000 0.4 15,000 5,000 0.25 1.2
R0.3, R0.5 25 8,000 1,300 0.6 15,000 10,000 0.25 1.2
R1 25 8,000 1,300 0.4 13,000 7,000 0.25 1.2
R0.5 30 7,000 1,500 0.3 13,000 12,000 0.3 1.5
R1 30 7,000 1,100 0.3 10,000 9,000 0.3 1.5
R0.5 35 6,000 1,300 0.3 10,000 15,000 0.2 1.5
R1 35 6,000 0.3 0.2 1.5
0.2 0.15
0.2 0.15 2
2
Ae

Depth of Cut Ap Ap
