2DRB RPM : rev./min Feed : mm/min

Material Aluminum Alloy Expanding Material Aluminum Alloys Casting / Die Casting Magnesium Alloy / Copper Allloy
A7075 Si1 3% Copper Allloy / CFRP C1100
AZ91 / AZ80A / C1100

Regular Milling High Speed Milling Regular Milling High Speed Milling Regular Milling High Speed Milling

Radius RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED

R0.1 32,000 220 45,000 290 32,000 220 45,000 290 32,000 220 45,000 290
R0.3 32,000 480 45,000 660 32,000 480 45,000 660 32,000 480 45,000 660
R0.5 28,800 760 45,000 1,100 28,800 760 45,000 1,100 28,800 760 45,000 1,100
R0.8 28,800 850 45,000 1,400 28,800 850 45,000 1,400 25,200 850 35,900 1,300
R1 28,600 1,400 45,000 2,000 28,600 1,400 43,000 1,900 21,500 1,000 35,900 1,600
R1.5 19,100 1,400 45,000 3,000 19,100 1,400 28,600 1,900 14,300 1,000 23,900 1,600
R2 14,300 1,400 35,900 3,200 14,300 1,400 21,400 1,900 10,700 1,000 17,900 1,600
R3 1,400 23,900 3,200 1,400 14,300 1,900 1,000 12,000 1,600
R4 9,500 1,800 17,600 4,100 9,500 1,800 10,700 2,400 7,200 1,300 2,000
R5 7,200 1,600 14,000 3,600 7,200 1,600 2,200 5,400 1,200 8,900 1,800
R6 5,700 1,500 11,700 3,400 5,700 1,500 8,600 2,000 4,300 1,100 7,200 1,700
4,800 Pf Pf 4,800 Pf 7,200 Pf 3,600 Pf 5,900 Pf
Ap 0.2D Ap 0.1D Ap 0.2D Ap 0.1D Ap 0.2D Ap 0.05D
0.1D 0.05D 0.1D 0.05D 0.1D 0.02D

Depth of Cut

2DRE / 3DRE Apply 20% up values of below condition for 3DRE RPM : rev./min Feed : mm/min

Material Aluminum Alloy Expanding Material Aluminum Alloys Casting / Die Casting Magnesium Alloy / Copper Allloy
A7075 Si1 3% Copper Allloy / CFRP C1100
AZ91 / AZ80A / C1100

Regular Milling High Speed Milling Regular Milling High Speed Milling Regular Milling High Speed Milling

Outside RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED
Diameter
450 410
0.5mm 28,800 160 45,000 500 28,800 160 45,000 540 28,800 140 45,000 500
0.6mm 28,800 180 45,000 590 28,800 180 45,000 720 28,800 160 45,000 590
0.8mm 28,800 200 45,000 770 28,800 200 45,000 960 26,100 180 45,000 630
1mm 28,800 200 45,000 900 28,800 200 45,000 1,000 20,700 200 37,800 630
1.2mm 28,800 210 45,000 1,100 28,800 210 45,000 1,100 17,100 200 32,400 630
1.5mm 28,800 250 45,000 1,400 28,800 250 45,000 1,100 14,000 200 26,600 680
2mm 28,800 400 45,000 1,800 28,800 380 45,000 1,100 13,000 200 25,200 680
2.5mm 22,500 540 43,200 1,900 22,500 540 27,900 1,100 230 18,000 680
3mm 18,900 630 36,000 1,900 18,900 630 23,400 1,200 8,600 230 15,300 720
4mm 14,000 650 29,700 2,000 14,000 650 18,000 1,500 7,200 250 12,600 860
5mm 11,300 680 27,900 2,500 11,300 680 17,280 1,500 5,400 270 11,300 900
6mm 750 23,400 2,500 750 14,310 1,600 4,300 280 900
8mm 9,500 800 17,550 2,600 9,500 800 10,800 1,700 3,600 270 9,500 1,000
10mm 7,200 900 13,950 2,900 7,200 900 1,700 2,600 330 7,100 1,000
12mm 5,700 950 11,700 2,900 5,700 950 8,640 Ap 2,100 350 5,700 Ap
4,800 Ap Ap Ae Ap 4,800 Ap 7,200 1,800 Ap 4,800
Ap Ae 0.3D Ap Ae 0.3D Ap Ae 0.15D Ap Ae 0.3D Ap Ae 0.1D
0.5 Dc 0.8 1D 0.1D 0.15D 0.5 Dc 0.8 0.5 Dc 0.8
1.5D 0.1D 0.5D 1.5D 0.1D 0.5D 1D 0.1D 1.5D 0.1D 0.5D 1D 0.05D
1 Dc 1 Dc 1 Dc

Depth
of Cut
