3COR RPM : rev./min Feed : mm/min

Slotting Side Cutting

Material Copper / Copper Alloys Copper / Copper Alloys

Outside Radius Effective RPM FEED Ap RPM FEED Ap Ap
Diameter Length
1mm R0.1, R0.2 45,000 2,500 Axial Depth 45,000 4,500 Axial Depth Radial Depth
1.5mm R0.1, R0.2 3 40,000 2,000 40,000 3,000
2mm R0.1, R0.2 6 35,000 1,600 0.036 35,000 2,000 0.036 0.2
2.5mm R0.1, R0.2 10 32,000 1,800 0.03 50,000 6,000 0.03 0.2
R0.1, R0.2 5 30,000 1,600 45,000 5,500 0.2
3mm R0.1, R0.2 8 30,000 1,500 0.025 40,000 4,500 0.025 0.3
R0.1, R0.2 12 35,000 1,800 0.08 45,000 5,000 0.08 0.3
4mm R0.1, R0.2 6 30,000 1,600 0.06 40,000 4,700 0.06 0.3
R0.1, R0.2 10 30,000 1,200 0.05 30,000 3,800 0.04 0.8
6mm R0.1, R0.2 14 32,000 2,000 0.14 40,000 5,300 0.12 0.6
R0.1, R0.2 8 30,000 1,900 0.12 38,000 5,300 0.1 0.4
8mm R0.1, R0.2 12 30,000 1,600 0.08 38,000 5,100 0.06 0.6
10mm 16 22,000 2,800 0.15 41,000 11,000 0.08 0.7
12mm R0.5 8 20,000 2,600 0.13 40,000 10,500 0.1 0.7
R0.5 12 20,000 2,500 0.13 40,000 10,200 0.1 0.8
R0.5 16 30,000 2,200 0.15 40,000 6,500 0.13 0.7
R0.2, R0.3 10 20,000 2,000 0.14 35,000 6,000 0.12 0.7
R0.2, R0.3 16 20,000 2,000 0.13 35,000 6,000 1.12
R0.2, R0.3 20 20,000 2,600 0.14 38,000 10,000 0.12 1
R0.5 10 20,000 2,200 0.12 35,000 8,000 0.1 0.6
R0.5 16 20,000 2,200 0.12 35,000 8,000 0.1 0.6
R0.5 20 20,000 2,600 0.14 40,000 8,000 0.12 0.8
R0.2, R0.3 12 15,000 2,400 0.12 32,000 5,000 0.1 0.6
R0.2, R0.3 16 15,000 2,000 0.12 32,000 5,000 0.1 0.6
R0.2, R0.3 20 20,000 2,400 0.5 35,000 10,000 0.18 0.12
R0.5 12 15,000 2,200 0.3 32,000 7,000 0.16 0.1
R0.5 16 15,000 2,200 0.25 32,000 7,000 0.15 0.8
R0.5 20 10,000 1,400 0.5 20,000 5,200 0.3 0.1
R0.3, R0.5 20 10,000 1,200 0.25 20,000 5,000 0.15 0.8
R0.3, R0.5 30 10,000 1,800 0.25 20,000 9,000 0.15 0.8
R1 20 10,000 1,500 0.6 20,000 7,000 0.25 1.2
R1 30 1,000 0.4 15,000 5,000 0.25 1.2
R0.3, R0.5 25 8,000 1,300 0.6 15,000 10,000 0.25 1.2
R1 25 8,000 1,300 0.4 13,000 7,000 0.25 1.2
R0.5 30 7,000 1,500 0.3 13,000 12,000 0.3 1.5
R1 30 7,000 1,100 0.3 10,000 9,000 0.3 1.5
R0.5 35 6,000 1,300 0.3 10,000 15000 0.2 1.5
R1 35 6,000 0.3 0.2 1.5
0.2 0.15
0.2 0.15 2
2
Ae

Depth of Cut Ap Ap
