TMD 5×D

DRILLING

● EXT Modular Shank Type

Code No. 치수 Dimension(mm) 센터드릴 인서트 부품 Component
Pilot Drill Insert Screw Driver
TMD-25050D D L1 L D1 Ds PLD-V0630
TMD-26050D
TMD-27050D 25 TiN WCMX030204 TSB-22045 TXL-6
TMD-28050D
TMD-29050D 26
TMD-30050D
TMD-31050D 27 150 210 WCMX040204 TSB-25055
TMD-32050D 28
TMD-33050D
TMD-34050D 29
TMD-35050D
TMD-36050D 30
TMD-37050D
TMD-38050D 31
TMD-39050D
TMD-40050D 32 175 235 50 28 TXL-8
TMD-41050D 33 WCMX050308 TSB-30070
TMD-42050D
TMD-43050D 34 PLD-V0835
TMD-44050D TiN
TMD-45050D 35
TMD-46050D 36
TMD-47050D
TMD-48050D 37
TMD-49050D
TMD-50050D 38 200 260
TMD-51050D 39
TMD-52050D
TMD-53050D 40
TMD-54050D 41
TMD-55050D
TMD-56050D 42
TMD-57050D
TMD-58050D 43 225 295 PLD-V1035 WCMX06T308 TSB-35090
TMD-59050D 44 TiN-H
45

46

47

48 250 320 TXL-15
49
50 63 36

51

52

53 275 345 PLD-V1238
54 TiN-H

55 WCMX080408 TSB-40110

56

57 300 370
58

59

※ TURBO DRILL은 일반 인써트 조립형 드릴의 한계인 직경의 5배 이상의 길이를 떨림없이 고속으로 드릴링 할 수 있으며 직경의
최대 8배까지 부드럽게 작업을 수행합니다.

※ Turbo Drill is capable of high speed drilling without vibrations for up to lengths 5 times greater than the diameter,
which is the drilling threshold for general insert assembly drills. It is capable of providing smooth drilling work for
up to size 8 times greater than the diameter.
