TMD 8×D

DRILLING

● EXT Modular Shank Type

Code No. 치수 Dimension(mm) 센터드릴 인서트 부품 Component
Pilot Drill Insert Screw Driver
TMD-25080D D L1 L D1 Ds PLD-V0630
TMD-26080D
TMD-27080D 25 TiN WCMX030204 TSB-22045 TXL-6
TMD-28080D
TMD-29080D 26
TMD-30080D
TMD-31080D 27 220 280 WCMX040204 TSB-25055
TMD-32080D 28
TMD-33080D
TMD-34080D 29
TMD-35080D
TMD-36080D 30
TMD-37080D
TMD-38080D 31
TMD-39080D
TMD-40080D 32 260 320 50 28 TXL-8
TMD-41080D 33 WCMX050308 TSB-30070
TMD-42080D
TMD-43080D 34 PLD-V0835
TMD-44080D TiN
TMD-45080D 35
TMD-46080D 36
TMD-47080D
TMD-48080D 37
TMD-49080D
TMD-50080D 38 300 360
TMD-51080D 39
TMD-52080D
TMD-53080D 40
TMD-54080D 41
TMD-55080D
TMD-56080D 42
TMD-57080D
TMD-58080D 43 340 410 PLD-V1035 WCMX06T308 TSB-35090
TMD-59080D 44 TiN-H
45

46

47

48 380 450 TXL-15
49
50 63 36

51

52

53 420 490 PLD-V1238
54 TiN-H

55 WCMX080408 TSB-40110

56

57 460 530
58

59

※ TURBO DRILL은 일반 인써트 조립형 드릴의 한계인 직경의 5배 이상의 길이를 떨림없이 고속으로 드릴링 할 수 있으며 직경의
최대 8배까지 부드럽게 작업을 수행합니다.

※ Turbo Drill is capable of high speed drilling without vibrations for up to lengths 5 times greater than the diameter,
which is the drilling threshold for general insert assembly drills. It is capable of providing smooth drilling work for
up to size 8 times greater than the diameter.
