VMD ACCESSORIES

DRILLING

CARTRIDGE

Drilling Range Inner Outer 인서트 No.of 부품 Component
45-50 VMC-045050N VMC-045050T Insert Insert Screw Driver
50-55 VMC-050055N VMC-050055T WCMX030204 TSB-22045 TXL-6
55-60 VMC-055060N VMC-055060T WCMX040204 2 TSB-25055
60-65 VMC-060065N VMC-060065T WCMX050308 2 TSB-30070 TXL-8
65-70 VMC-065070N VMC-065070T 2
70-75 VMC-070075N VMC-070075T WCMX06T308 TSB-35090 TXL-15
75-80 VMC-075080N VMC-075080T WCMX050308 2 TSB-30070 TXL-8
80-85 VMC-080085N VMC-080085T 3
85-90 VMC-085090N VMC-085090T WCMX06T308 TSB-35090
90-95 VMC-090095N VMC-090095T 3 TXL-15
95-100 VMC-095100N VMC-095100T WCMX080408
100-105 VMC-100105N VMC-100105T 3 TSB-40110
105-110 VMC-105110N VMC-105110T
110-115 VMC-110115N VMC-110115T
115-120 VMC-115120N VMC-115120T
120-125 VMC-120125N VMC-120125T
125-130 VMC-125130N VMC-125130T
130-135 VMC-130135N VMC-130135T
135-140 VMC-135140N VMC-135140T
140-150 VMC-140150N VMC-140150T
150-160 VMC-150160N VMC-150160T
160-170 VMC-160170N VMC-160170T
170-180 VMC-170180N VMC-170180T

※ VMD 카트리지는 바디의 수명을 연장시키고 바깥쪽 카트리지 단면을 밀링 작업으로 직경을(5mm)조절할 수 있습니다.
※ Please place an order shorten the length of outer cartridge if smaller dia. is needed.(ex:ø77=by1.5mm cutting MDC-075080T)

PILOT DRILL Code No. 치수 Dimension(mm)
DL

PLD-V1035 TiN-H 10 35
PLD-V1238 TiN-H 12 38
PLD-V1645 TiN-H 16 45
PLD-2045 TiN-H 20 56
PLD-2556 TiN-H 25 68
PLD-3068 TiN-H 30

※ ex:PLD-2556 TiN-H(25TiN coated oil hole)

DRIVE RING Code No. 치수 Dimension(mm)
DVR-281310
DVR-321610 D dS
DVR-402212
DVR-482712 28 13 10
DVR-583214 32 16
DVR-704014 40 22
DVR-805016 48 27 12

58 32 14
70 40
80 50 16
