Hydraulic
Chuck

ER COLLET CHUCK (LONGTYPE) ER Shrink Fit
Holder

Milling
Chuck

H

D

SK Slim
Chuck

TAPER No. L NUT ER Collet
Chuck

JIS B6339-BT JIS B6339 Taper G Value RPM Coolant N&COHDtroilhlledreCrThsouoclk
- BT Accuracy 6.3 15,000 System

AT3 A

Unit : mm Morse Taper

TAPER No. MODEL No. CLAMPING RANGE L D H NUT / COLLET 중량(Kg) 재고 Arbor
50 BT50-ER11-200 0.5 - 0.7 200
BT50-ER16-200 0.5 - 10.0 200 19 28.6 SQ-ER11 / ER11
BT50-ER16-250 0.5 - 10.0 250
BT50-ER16-300 0.5 - 10.0 300 28 36.6 SQ-ER16 / ER16
BT50-ER20-200 0.5 - 13.0 200
BT50-ER20-250 0.5 - 13.0 250 28 36.6 SQ-ER16 / ER16
BT50-ER20-300 0.5 - 13.0 300
BT50-ER25-200 1.0 - 16.0 200 28 36.6 SQ-ER16 / ER16 Synchro Tapping Chuck
BT50-ER25-250 1.0 - 16.0 250
BT50-ER25-300 1.0 - 16.0 300 34 44.5 SQ-ER20 / ER20
BT50-ER32-200 1.0 - 20.0 200
BT50-ER32-250 1.0 - 20.0 250 34 44.5 SQ-ER20 / ER20
BT50-ER32-300 1.0 - 20.0 300
BT50-ER32-350 1.0 - 20.0 350 34 44.5 SQ-ER20 / ER20
BT50-ER40-200 2.0 - 30.0 200
BT50-ER40-250 2.0 - 30.0 250 42 65 SQ-ER25 / ER25 Tapping ER
BT50-ER40-300 2.0 - 30.0 300 Chuck
BT50-ER40-350 2.0 - 30.0 350 42 65 SQ-ER25 / ER25

42 65 SQ-ER25 / ER25

50 65 SQ-ER32 / ER32

50 65 SQ-ER32 / ER32

50 65 SQ-ER32 / ER32 Tapping
Chuck
50 65 SQ-ER32 / ER32

63 75 SQ-ER40 / ER40

63 75 SQ-ER40 / ER40

63 75 SQ-ER40 / ER40 Side Lock Arbor
& End Mill Holder
63 75 SQ-ER40 / ER40

▶ CAT(ANSI B5.50) Taper 및 Inch Type 제품 공급 가능
▶ ER Collet 적용범위 111-114page 참고
▶ ER Nut, Sealing disk, Spanner 적용범위 115-121page 참고

Face Mill
Arbor

Shell Mill
Arbor

Boring
System
