TOOL HTOOOLLDHEOLRDER SYSTEM7
ER COLLET CHUCK

▶ GER COLLET

GER ㎜

L D RUNOUT(TIR)
6 1.0-1.4 0.015
10 1.5-2.9 0.015
16 3.0-5.9 0.015
25 6.0-9.9 0.015
40 10.0-17.9 0.02
50 18.0-26.9 0.02

㎜

CODE NO. d1 D1 L1 CHUCK NUT

GER11 (Clamping Range) 11.5 18.0 ER11 ERN11
GER16 17.0 27.5 ER16 ERN16
GER20 1.0-7.0 21.0 31.5 ER20 ERN20
GER25 1.0-10.0 26.0 34.0 ER25 ERN25
GER32 1.0-13.0 33.0 40.0 ER32 ERN32
GER40 1.0-16.0 41.0 46.0 ER40 ERN40
2.0-20.0
GER11 3.0-26.0
GER16
GER20 ㎜
GER25
툴홀더 시스템 GER32 ER COLLET CODE NO. (d)1 SET
GER40 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0 13PCS
1, 2, 3, 4, 5, 6, 7, 8, 9, 10 10PCS
2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 12PCS
2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16 15PCS
3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20 18PCS
4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26 23PCS
