HD TYPE 8

▶ HDSC-TYPE LIVE CENTER

※ 보급형 라이브센터
※ 범용장비 사용에 적합
※ 적정 RPM(3800)이하

Model Order Morse GL A Dimension Weight R.P.M Run
Number Taper B L1 L2 L3 L4 L5 C L MAX. MAX. Out
LC-3HDSC 23.825 36
LC-4HDSC 071012 NO.3 31.267 38 18 27.5 40.5 5 73 81 10 154 80 4500 0.003
LC-5HDSC 071013 NO.4 44.399 64
LC-6HDSC 071014 NO.5 63.384 86 22 32 42.5 6 80.5 102.5 14 183 80 4500 0.003
071015 NO.6
30 47 56.5 10 113.5 129.5 18 243 230 2000 0.005

42 60 66.5 10 136.5 182 30 318.5 600 1500 0.005

▶ HDSTH-TYPE

※ 나사가공전용 타입
※ 3중 베어링 적합
※ 절삭유에 잘 견디는 구조
※ 적정 RPM(3800)이하

Model Order Morse Dimension Weight R.P.M Run

Number Taper GL A B b L1 L2 L3 L4 L5 L6 L MAX. MAX. Out

LC-3HDSTH-06 073011 6 12.6

LC-3HDSTH-08 073012 NO.3 23.825 36 18 8 16.3 35 40.5 5 80.5 81 161.5 55
LC-3HDSTH-10 073013 10 20.1

LC-3HDSTH-12 073014 12 23.8

LC-4HDSTH-06 074011 6 10.1

LC-4HDSTH-08 074012 NO.4 31.267 38 20 8 13.9 36.2 40.5 6 84.5 102.5 187 65 3800 0.003
LC-4HDSTH-10 074013 10 17.6

LC-4HDSTH-12 074014 12 21.3

LC-5HDSTH-06 075011 6 13.4

LC-5HDSTH-08 075012 NO.5 44.399 64 24 8 17.1 47 56.5 10 113.5 129.5 243 150
LC-5HDSTH-10 075013 10 20.8

LC-4HDSTH-12 075014 12 24.6

▶ HD SPECIAL

라이브센터 시리즈
