2 Flutes Micro Rib End Mills

2

0 0.01 0.01 0.025 Endmills for Acryl, A.B.S, Aluminum, non-ferrous and
non-metallic materials.
0.2 ~ 6 Sharp Edge Minimize chattering by short flute design.
Excellent tool rigidity by short flute design at high speed, feed
machining.
Reinforced edge design for preventing edge chipping.
Excellent wear resistance by applying fine WC grade.

D Size D Tolerance
0.2 ~ 5 +0 ~ -0.01mm

6 -0.01 ~ -0.025mm

mm

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia of cut Length Length Dia
FOR A.B.S 2MRE 002 005 S04 D L1 L2 L d 2MRE 014 100 S04 D L1 L2 L d
2MRE 002 010 S04 2MRE 014 160 S04
2MRE 002 015 S04 0.2 0.3 0.5 40 4 2MRE 015 060 S04 1.4 2.8 10 50 4
2MRE 002 020 S04 0.2 0.3 1 40 4 2MRE 015 100 S04 1.4 2.8 16 50 4
2MRE 003 010 S04 0.2 0.3 1.5 40 4 2MRE 015 140 S04 1.5 3 6 50 4
2MRE 003 020 S04 0.2 0.3 2 40 4 2MRE 015 160 S04 1.5 3 10 50 4
2MRE 003 030 S04 0.3 0.45 1 40 4 2MRE 015 200 S04 1.5 3 14 50 4
2MRE 003 050 S04 0.3 0.45 2 40 4 2MRE 015 250 S04 1.5 3 16 50 4
2MRE 004 020 S04 0.3 0.45 3 40 4 2MRE 015 300 S04 1.5 3 20 60 4
2MRE 004 030 S04 0.3 0.45 5 40 4 2MRE 016 060 S04 1.5 3 25 60 4
2MRE 004 040 S04 0.4 0.6 2 40 4 2MRE 020 080 S04 1.5 3 30 70 4
2MRE 004 050 S04 0.4 0.6 3 40 4 2MRE 020 100 S04 1.6 3.2 6 50 4
2MRE 004 060 S04 0.4 0.6 4 40 4 2MRE 020 120 S04 2 4 8 50 4
2MRE 005 020 S04 0.4 0.6 5 40 4 2MRE 020 140 S04 2 4 10 50 4
2MRE 005 040 S04 0.4 0.6 6 40 4 2MRE 020 160 S04 2 4 12 50 4
2MRE 005 060 S04 0.5 1 2 45 4 2MRE 020 180 S04 2 4 14 50 4
2MRE 005 080 S04 0.5 1 4 45 4 2MRE 020 200 S04 2 4 16 50 4
2MRE 005 100 S04 0.5 1 6 45 4 2MRE 020 250 S04 2 4 18 50 4
2MRE 006 020 S04 0.5 1 8 45 4 2MRE 020 300 S04 2 4 20 60 4
2MRE 006 040 S04 0.5 1 10 45 4 2MRE 020 350 S04 2 4 25 60 4
2MRE 006 060 S04 0.6 1.2 2 45 4 2MRE 020 400 S04 2 4 30 70 4
2MRE 006 080 S04 0.6 1.2 4 45 4 2MRE 025 120 S04 2 4 35 80 4
2MRE 006 100 S04 0.6 1.2 6 45 4 2MRE 025 200 S04 2 4 40 80 4
2MRE 007 040 S04 0.6 1.2 8 45 4 2MRE 030 080 S06 2.5 5 12 60 4
2MRE 007 060 S04 0.6 1.2 10 45 4 2MRE 030 120 S06 2.5 5 20 60 4
2MRE 007 080 S04 0.7 1.4 4 45 4 2MRE 030 160 S06 3 6 8 70 6
2MRE 007 100 S04 0.7 1.4 6 45 4 2MRE 030 200 S06 3 6 12 70 6
2MRE 008 040 S04 0.7 1.4 8 45 4 2MRE 030 250 S06 3 6 16 70 6
2MRE 008 060 S04 0.7 1.4 10 45 4 2MRE 030 300 S06 3 6 20 70 6
2MRE 008 080 S04 0.8 1.6 4 45 4 2MRE 030 400 S06 3 6 25 70 6
2MRE 008 100 S04 0.8 1.6 6 45 4 2MRE 030 450 S06 3 6 30 80 6
2MRE 008 120 S04 0.8 1.6 8 45 4 2MRE 040 120 S06 3 6 40 90 6
2MRE 009 060 S04 0.8 1.6 10 45 4 2MRE 040 160 S06 3 6 45 90 6
2MRE 009 100 S04 0.8 1.6 12 45 4 2MRE 040 200 S06 4 8 12 70 6
2MRE 009 120 S04 0.9 1.8 6 45 4 2MRE 040 250 S06 4 8 16 70 6
2MRE 010 060 S04 0.9 1.8 10 45 4 2MRE 040 300 S06 4 8 20 70 6
2MRE 010 080 S04 0.9 1.8 12 45 4 2MRE 040 350 S06 4 8 25 70 6
2MRE 010 100 S04 1 2 6 50 4 2MRE 040 400 S06 4 8 30 70 6
2MRE 010 120 S04 1 2 8 50 4 2MRE 040 500 S06 4 8 35 80 6
2MRE 010 160 S04 1 2 10 50 4 2MRE 050 160 S06 4 8 40 80 6
2MRE 010 200 S04 1 2 12 50 4 2MRE 050 250 S06 4 8 50 100 6
2MRE 010 250 S04 1 2 16 50 4 2MRE 050 350 S06 5 10 16 80 6
2MRE 012 060 S04 1 2 20 60 4 2MRE 060 250 S06 5 10 25 80 6
2MRE 012 080 S04 1 2 25 60 4 2MRE 060 350 S06 5 10 35 80 6
2MRE 012 100 S04 1.2 2.4 6 50 4 2MRE 060 500 S06 6 12 25 80 6
2MRE 012 120 S04 1.2 2.4 8 50 4 2MRE 060 600 S06 6 12 35 80 6
2MRE 012 160 S04 1.2 2.4 10 50 4 6 12 50 120 6
2MRE 014 060 S04 1.2 2.4 12 50 4 6 12 60 120 6
1.2 2.4 16 50 4
1.4 2.8 6 50 4
