3 Flutes Micro Rib End Mills

3

Endmills for Acryl, A.B.S, Aluminum, non-ferrous and
non-metallic materials.
Minimize chattering by short flute design.
Excellent tool rigidity by short flute design at high speed, feed
machining.
Reinforced edge design for preventing edge chipping.
Excellent wear resistance by applying fine WC grade.

0 0.01 0.01 0.025 0.015 0.03 D Size D Tolerance
1~4 +0 ~ -0.01mm
6 ~ 12 -0.01 ~ -0.025mm
16 -0.015 ~ -0.03mm

1~ 6~ 16 Sharp Edge mm

Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia
3MRE 010 050 S04 D L1 L2 L d
3MRE 010 100 S04
3MRE 010 150 S04 1 3 5 70 4
3MRE 010 200 S04 1 3 10 70 4
3MRE 010 250 S04 1 3 15 70 4
3MRE 015 100 S04 1 3 20 70 4
3MRE 015 150 S04 1 3 25 70 4
3MRE 015 200 S04 1.5 4.5 10 70 4
3MRE 015 250 S04 1.5 4.5 15 70 4
3MRE 015 300 S04 1.5 4.5 20 70 4
3MRE 020 100 S04 1.5 4.5 25 70 4
3MRE 020 150 S04 1.5 4.5 30 70 4
3MRE 020 200 S04 2 6 10 70 4
3MRE 020 250 S04 2 6 15 70 4
3MRE 020 300 S04 2 6 20 70 4
3MRE 030 200 080 2 6 25 70 4
3MRE 030 200 S04 2 6 30 70 4
3MRE 030 300 100 3 15 20 80 3
3MRE 030 300 S04 3 9 20 80 4
3MRE 040 200 080 3 15 30 100 3
3MRE 040 300 100 3 9 30 80 4
3MRE 060 300 100 4 12 20 80 4
3MRE 060 400 150 4 12 30 100 4
3MRE 080 400 120 6 18 30 100 6
3MRE 080 500 150 6 18 40 150 6
3MRE 100 500 120 8 24 40 120 8
3MRE 100 600 150 8 24 50 150 8
3MRE 120 600 150 10 30 50 120 10
3MRE 160 700 160 10 30 60 150 10
12 36 60 150 12
16 54 70 160 16
