2CHA RPM : rev./min Feed : mm/min

Material Carbon Steels Alloy steels Prehardened Steels/ Hardened Steels
S45C / S50C SK / SCM / SUS NAK / SCM / SUS
Hardness
Velocity ~ 225HB 225 ~ 325HB 30 ~ 45HRc

Shank Diameter Vc = 25 ~ 50m/min Vc = 20 ~ 40m/min Vc = 15 ~ 40m/min
3mm
4mm RPM FEED RPM FEED RPM FEED
6mm
8mm 2,700 ~ 5,300 59 ~ 86 2,100 ~ 4,200 46 ~ 67 1,600 ~ 3,200 35 ~ 51
10mm 2,000 ~ 4,000 48 ~ 68 1,600 ~ 3,200 38 ~ 54 1,200 ~ 2,400 29 ~ 41
12mm 1,300 ~ 2,700 36 ~ 49 1,100 ~ 2,100 31 ~ 42 22 ~ 30
1,000 ~ 2,000 32 ~ 42 26 ~ 34 800 ~ 1,600 22 ~ 30
30 ~ 37 800 ~ 1,600 23 ~ 29 600 ~ 1,200 17 ~ 22
800 ~ 1,600 28 ~ 35 640 ~ 1,300 21 ~ 27 600 ~ 1,200 17 ~ 22
700 ~ 1,300 530 ~ 1,100
400 ~ 800

Depth of Cut

Water Soluble or Oil Cutting fluid is recommended.

3CHA RPM : rev./min Feed : mm/min

Material Carbon Steels Alloy steels Prehardened Steels/ Hardened Steels
S45C / S50C SK / SCM / SUS NAK / SCM / SUS
Hardness
Velocity ~ 225HB 225 ~ 325HB 30 ~ 45HRc

Shank Diameter Vc = 25 ~ 50m/min Vc = 20 ~ 40m/min Vc = 15 ~ 40m/min
3mm
4mm RPM FEED RPM FEED RPM FEED
6mm
8mm 2,700 ~ 5,300 47 ~ 69 2,100 ~ 4,200 37 ~ 54 1,600 ~ 3,200 28 ~ 41
10mm 2,000 ~ 4,000 38 ~ 54 1,600 ~ 3,200 30 ~ 43 1,200 ~ 2,400 23 ~ 33
12mm 1,300 ~ 2,700 29 ~ 39 1,100 ~ 2,100 25 ~ 34 18 ~ 24
1,000 ~ 2,000 26 ~ 34 21 ~ 27 800 ~ 1,600 18 ~ 24
24 ~ 30 800 ~ 1,600 18 ~ 23 600 ~ 1,200 14 ~ 18
800 ~ 1,600 22 ~ 28 640 ~ 1,300 17 ~ 22 600 ~ 1,200 14 ~ 18
700 ~ 1,300 530 ~ 1,100
400 ~ 800

Depth of Cut

Water Soluble or Oil Cutting fluid is recommended.

2CEN RPM : rev./min Feed : mm/min
Aluminum Alloys
Mild Steels / Carbon Steels Alloy Steels / Tools Steels Prehardened Steels
Material SS400 / S55C SKD / SUS / SCM HPM / NAK (30~45HRC)

Outside Diameter RPM FEED RPM FEED RPM FEED RPM FEED

2mm 1,400 100 800 50 650 40 4,800 280
3mm 1,400 100 800 50 650 40 4,800 280
4mm 1,280 100 690 50 580 40 4,200 280
5mm 1,300 100 640 50 520 40 3,300 280
6mm 1,150 100 600 50 480 40 2,900 280
8mm 1,000 100 530 50 420 40 2,600 280
10mm 490 40 390 30 2,400 260
12mm 850 90 410 40 310 30 1,900 260
14mm 720 90 340 40 270 30 1,700 240
16mm 610 90 310 40 250 30 1,500 230
550 90

Depth of Cut
