4TES / 4TRS / 4&6TDA / 4&6TAC RPM : rev./min Feed : mm/min

Side Cutting

Material Mild Steels / Carbon Steels Alloy Steels Prehardened Steelss
SS400 / S55C SKD / SUS / SCM NAK / HPM
Outside Diameter
RPM FEED RPM FEED RPM FEED
1.5mm
2mm 3,050 162 1,890 94 1,530 76
2.5mm 2,850 149 1,790 88 1,440 70
3mm 2,680 135 1,700 83 1,350 65
4mm 2,500 122 1,610 79 1,260 59
5mm 2,150 108 1,430 72 1,080 54
6mm 1,800 1,200 65 49
8mm 1,430 95 58 900 43
10mm 1,070 86 950 43 720 32
12mm 64 720 34 540 26
860 52 580 29 430 22
720 43 480 360

Depth of Cut

Slotting

Material Mild Steels / Carbon Steels Alloy Steels Prehardened Steelss
SS400 / S55C SKD / SUS / SCM NAK / HPM
Outside Diameter
RPM FEED RPM FEED RPM FEED
1.5mm
2mm 3,050 117 1,890 77 1,530 59
2.5mm 2,850 110 1,790 72 1,440 55
3mm 2,680 1,700 66 1,350 50
4mm 2,500 99 1,610 60 1,260 45
5mm 2,150 92 1,430 54 1,080 41
6mm 1,800 81 1,200 47 35
8mm 1,430 70 39 900 30
10mm 1,070 59 950 30 720 22
12mm 44 720 23 540 17
860 35 580 20 430 14
720 30 480 360

Depth of Cut

1MEM / 1REM

Material Acrylic Alloy Steels

Outside Diameter RPM FEED RPM FEED

1mm 32,000 2,000 23,000 1,300
2mm 32,000 2,200 23,000 1,500
3mm 25,000 2,400 18,000 1,700
4mm 20,000 2,400 15,000 1,800
5mm 15,000 2,200 12,000 1,800
6mm 13,500 2,300 10,000 1,800
8mm 10,000 2,400 1,900
10mm 2,400 7,800 2,000
12mm 8,000 2,200 6,000 1,900
7,000 5,000

Depth of Cut
